IMO VXSM550-3 - External Dimensions: VXSM550-3, VXSM750-3, and Keypad

Specifications 9-10
9
Installation screw :size : M5 (4pcs)
VXSM550-3
VXSM750-3
70
34.32
21.82
12.5
60.5
2-ø3.2
Counter bore ø6.6, depth 4
4.75
4.75
42
27
15
32.54.75
4.75
Front view Side view
RJ45
Connector
RUN
P R G
RESET
STOP
FUNC
DATA
RJ45 Connector
17
53
Clearance hole for RJ45
Connector to be o26
Top view
VXSM Keypad
