User Manual
Code: IPC-A42P
IP PTZ CAMERA INDOOR IPC-A42P Wi-Fi RANGER 2 - 3.7 Mpx 3.6 mm
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2022-01-13 IPC-A42P 2/5
IP PTZ camera with efficient H.265 / H.264 image compression algorithm for clear
and smooth video streaming at max. resolution of 4 Mpx.
The cameras of the IMOU series have been designed with special care to simplify
the configuration and operation. In combination with the user friendly IMOU
platform, the IMOU series devices allow anyone to create a simple and effective
surveillance system.
Very easy operation via mobile devices (Android / iOS), allows the users for
comfortable and remote operation, and also management of the camera. The used
Wi-Fi module allows to remote communication with camera for max. distance up to
50 m.
The device is ideal for eg. as a baby monitor, with mobile image view on
smartphone and possibility of bi-directional audio transmission.
In order to obtain optimal performance of IMOU series cameras, it is recommended
to use DAHUA Micro SD memory cards.
Attention! The IMOU series devices do not have a WEB interface.
Standard: TCP/IP
Sensor: 1/2.7 " Progressive Scan CMOS
Matrix size: 4 Mpx
Resolution: 2560 x 1440 - 3.7 Mpx
Lens: 3.6 mm
View angle: 92 ° (manufacturer data)
Range of IR illumination: 10 m
Horizontal rotation range: 355 °
Vertical rotation range: -5 ° ... 80 °
Audio:
• Microphone built-in,
• Speakers built-in,
• Bi-directional audio streaming support
Image compression method: H.265 / H.264
Main stream frame rate: 25 fps @ 1080p
Network protocols: TCP, DHCP
ONVIF:
Network interface: 10/100 Base-T (RJ-45), Wi-Fi IEEE 802.11 b/g/n
