10
Exploded View and Parts List
Right Front Frame ASSY
Left Front Frame ASSY
ItemNo.
Grade No. Part No. Description QTY
1 4.1 IF93250400 Right Front Frame 1
2 4.2 IF93272000 Foot Plate 1
ItemNo.
Grade No. Part No. Description QTY
1 5.1 IF93250500 Left Front Frame 1
2 5.2 IF93272000 Foot Plate 1
