Impulse IF9325 - Bottom Cross Frame ASSY; Top Cross Frame ASSY

9
Exploded View and Parts List
Bottom Cross Frame ASSY Top Cross Frame ASSY
ItemNo.
Grade No. Part No. Description QTY
1 2.1 IF93250200 Bottom Cross Frame 1
2 2.2 KPSFID2800 Plug 2
3 2.3 IF93272000 Foot Plate 1
4 2.4 PE3000900 Adjustment Frame 2
5 2.5 PE3001200 Rubber Bumper 2
ItemNo.
Grade No. Part No. Description QTY
1 3.1 IF93250300 Top Cross Frame 1
2 3.2 KPSFID2800 Plug 2
3 3.3 RSM625WS20000 Plug 4
