Impulse IF9325 - Assembly; STEP 7 Short Shroud

30
Assembly
STEP 7
1. Attach the Short Shroud Retainer Plate (#41) to the the Main Frame ASSY (#1) using:
six Cross Disc Self Tapping Screw ST4.2*16 (#38)
2. Attach the Short Rear Shroud (#42) to the Short Shroud Retainer Plate (#41) using:
four Button (#39)
Note: Wrench Tighten Bolts and Nylon Lock Nuts.
Short Shroud
