8
Exploded View and Parts List
Floor Stand Frame 1 ASSY Floor Stand Frame 2 ASSY
ItemNo. Grade No.
Part No. Description QTY
1 1.1 SL70380100 Floor Stand Frame 1 1
2 1.2 CWRVL0051200 Rubber Foot 2
ItemNo. Grade No.
Part No. Description QTY
1 2.1 SL70380200 Floor Stand Frame 2 1
2 2.2 SL70383100 Rotating Sleeve Φ26*3*55 1
3 2.3 IN-S51102100 Aluminum Cap Φ50*Φ10.5*8 1
4 2.4 CWRVL0051200 Rubber Foot 2
5 2.5 CNLM10*25DS20 Flat Head Cap Screw M10*25 1
