Impulse SL7038 - Page 9

9
Exploded View and Parts List
Back Pad Frame ASSY Seat Pad Frame ASSY
ItemNo. Grade No.
Part No. Description QTY
1 3.1 SL70380400 Back Pad Frame 1
2 3.2 VLP8000
Pulg □50*100
1
ItemNo. Grade No.
Part No. Description QTY
1 4.1 SL70380700 Seat Pad Frame 1
2 4.2 IF93035000 Inner Wear Sleeve 2
3 4.3 GB70M10*30DHS20 Socket Head Cap Screw M10*30 1
