11
Exploded View and Parts List
Adjustable Tube ASSY
Foot Tube ASSY
Foam Tube ASSY
ItemNo. Grade No. Part No. Description QTY
1 11.1 SL70411500 Adjustable Tube 1
2 11.2 M02701000 Pipe Plug
□
50 1
ItemNo. Grade No. Part No. Description QTY
1 12.1 SL70411600 Foot Tube 1
2 12.2 HF6031500 Grip DTΦ36*Φ30*205 1
ItemNo. Grade No. Part No. Description QTY
1 13.1 ABS70130700 Foam Tube 1
2 13.2 IF81165000 Sun Nut 2
