Inboard M1 - CHARGING YOUR POWERSHIFT BATTERY

Power Gauge
Must align properly to
close Bay Door
Magnetic Power Port
Battery Terminals
DO NOT TOUCH
CHARGING YOUR POWERSHIFT BATTERY
NOTE: Charge time approximately 90 min. Recommended
charging temperature range: 0-50 °C / 32-122 °F.
CHARGING STEPS
1. Connect your PowerShift Battery charger to a power outlet
2. Connect the Magnetic Power Link connector from the charger to
the PowerShift Battery Power Port
The PowerShift Battery charger LEDs will now light up green and run
in a ‘charging’ sequence.
You will know that your PowerShift Battery is fully charged when the
charger’s LEDs no longer light in a sequence. To double check, press
the status button on the PowerShift Battery, 5 Red Status LEDs will
light up indicating the Battery is fully charged.
| 17
