4 of 33
Service Manual UK
Indesit
Company
English
INTRODUCTION OF INDESIT TOUCH CONTROL INDUCTION HOB VIX644CE
VIX644CE was introduced into the Indesit built-in range in June 2013. This model complies with the
new Stand-By and safety regulations. It has 4 cooking zones with 4 individual controls. 2 x 1.5kW -
Boost to 2kW, 2 x 1.2 kW - Boost to 1.6 kW. Child Lock, Touch Control, Heat Indicators and 9 Power
Levels.
TECHNICAL SPECIFICATIONS
Model No. Commercial Code Colour
VIX644CE 82475 Frameless Black Glass
Legend
Country of Origin Poland
Position of Rating Plate Underside of base plate
Overall Dimensions Height Width Depth
Unpacked 53mm 590mm 510mm
Packed 90mm 680mm 580mm
Aperture Size Width = 560mm, Depth = 490mm
Weight Gross = 9.5kg, Net = 8.3kg
Electrical Supply 230/240Volts AC @ 50Hz
Earthing Requirement This hob MUST be Earthed
Heating Zones
Position
Front Right 1.2 kW - Boosts to 1.6 kW
Front Left 1.5 kW - Boosts to 2kW
Back Right 1.5 kW - Boosts to 2 kW
Back Left 1.2 kW - Boosts to 1.6 kW
VI X 6 4 4 C E
Vitroceramic 6 = 60 cmPremier
Interface
Boosters Crystal EntryInduction Zones
