Indmar 5.7L MPI User Manual

B-2
Indmar Marine Engines
Fluid Capacities 5.7L Carbureted 5.7L MPI L96 LS3 LSA
Crankcase (With Filter) 5.5 Quarts (5.25L)* 6.0 Quarts (5.7L) 8.5 Quarts (8.0L)
Closed Cooling System 12-14 Quarts (11.4-13.3L)
In-Line 1:1 Transmission 1.7 Quarts (1.6L) Dexron 3 ATF
In-Line Reduction Gear 2.12 Quarts (2L) 15W40
ZF Ski Vee Transmission 2.12 Quarts (2L) Main Gearbox, 1.0 Quart (1.06L) V-Drive - Dexron 3
Indmar-Vee Transmission 2.3 Quarts (2.12L) Main Gearbox - Dexron 3, 1.25 Quart (1.18L) V-Drive - Mobil Delvac Synthetic 50
ZF 63IV Transmission 4.2 Quarts (4L) 15W40
Walter V-Drive 0.5 Quart (0.5L) 15W40 Motor Oil
* The Skier’s Choice Premium 5.7L (SC350) is equipped with a special oil pan with a capacity of approximately 7 quarts (6.6L). Always fill the oil to
the “FULL” mark on the dipstick.
