4 panel LEDs are racing downwards
The Smart PRO is in charging mode and your EV is currently being charged.
Green when a charge is scheduled
The Smart PRO is not currently charging, but the EV is connected and a charging
session has been scheduled.
Flashing Green - Fixed Load Calibration
The installation engineer has triggered the Fixed Calibration Load function as part of
the charger’s set-up process. This will only be seen by the installer during installation.
LEDs relating to the primary LED light:
4 panel LEDs are o
If the four panel LEDs below the primary LED are o, then the Smart PRO is not
connected to the EV.
4 panel LEDs are lit
With the four panel LEDs illuminated, the Smart PRO is connected to the EV
and is currently in ‘idle’ mode, waiting to charge.
4
4 panel LEDs ashing, white
The vehicle is no longer accepting charge. It is likely that the battery is fully charged.
4
