Industrial Shields M-DUINO PLUS series - General Features

Ref. IS.MDUINO.XXX
1.5 General Features
CONECTABLE PLC ARDUINO 24Vcc M-DUINO
MODEL TYPE
B Zone
B+C Zone
B+C+D
Zone
Input Voltage
12 to 24Vdc
Fuse protection (2.5A)
Polarity protection
I max.
1.5A
Size
101x119.5x70.1
101x119.5x94.7
101x119.5x119.3
Clock Speed
16MHz
Flash Memory
256KB of which 8KB used by bootloader
SRAM
8KB
EEPROM
4KB
Communications
I2C – Ethernet Port – USB – RS485 – RS232 -- SPI
– (2x) Rx, Tx (Arduino pins)
Max232-Max485-
W5500
USB consideration!
Only meant for uploading or debugging, not
always connected as a serial in a project!
Cannot be working in
a final application
An/Dig Input 10bit
(0-10Vcc)
0 to 10V
Input Impedance: 39K
Separated PCB ground
Digital Isolated Input
(24Vcc)
7 to 24Vdc
I min: 2 to 12 mA
Galvanic Isolation
* Interrupt isolated
Input HS (24Vcc)
7 to 24Vdc
I min: 2 to 12 mA
Galvanic Isolation
Analog Output 8bit
(0-10Vcc)
0 to 10Vdc
I max: 20 mA
Separated PCB ground
Digital Isolated
Output (24Vcc)
5 to 24Vdc
I max: 70 mA
Galvanic Isolation
Diode Protected for Relay
Imax 24Vdc: 410 mA
Digital Isolated
Output Relay
220V Vac
I max: 5A
Galvanic Isolation
Diode protected for Relay
PWM Isolated Output
8bit (24Vcc)
5 to 24Vdc
I max: 70 mA
Galvanic Isolation
Diode Protected for Relay
Relay Output
I max: 5A
V max: 24VDC / 230VAC
Expandability
I2C - 127 elements - Serial Port RS232/RS485
* By using this type of signal can no longer use Digital signal
(24Vdc)
