Industrial Shields M-DUINO PLUS series - Technical Specifications; General Specifications; Performance Specification

Ref. IS.MDUINO.XXX
Technical Specifications:
2.1 General Specifications:
Item
M-DUINO B ZONE
M-DUINO B+C ZONE
M-DUINO B+C+D ZONE
Power supply
voltage
DC power supply
12 to 24Vdc
Operating
voltage range
DC power supply
11.4 to 25.4Vdc
Power
consumption
DC power supply
30VAC max.
External
power supply
Power supply
voltage
24Vdc
Power supply
output capacity
700Ma
Insulation resistance
20MΩ min.at 500Vdc between the AC terminals and the protective earth terminal.
Dielectric strength
2.300 VAC at 50/60 Hz for one minute with a leakage current of 10mA max. Between all
the external AC terminals and the protective ground terminal.
Shock resistance
80m/s
2
in the X, Y and Z direction 2 times each.
Ambient temperature (operating)
0º to 45ºC
Ambient humidity (operating)
10% to 90% (no condensation)
Ambient environment (operating)
With no corrosive gas
Ambient temperature (storage)
-20º to 60ºC
Power supply holding time
2ms min.
Weight
445g max.
542g max.
850g max.
2.2 Performance Specification:
Arduino Board
ARDUINO MEGA 2560
Control method
Stored program method
I/O control method
Combination of the cyclic scan and immediate refresh processing methods.
Programming language
Arduino IDE. Based on wiring (Wiring is an Open Source electronics platform composed of a
programming language. “similar to the C”. http://arduino.cc/en/Tutorial/HomePage
Microcontroller
ATmega2560
Flash Memory
256KB of which 8KB are used by the bootloader
Program capacity (SRAM)
8KB
EEPROM
4KB
Clock Speed
16MHz
Clock Speed
16MHz
