SP37
Tire Pressure Monitoring Sensor
ROM Library Functions
ROM Library Function Guide 52 Revision 1.0, 2011-12-15
2.5.6 Resource Usage
2.5.7 Execution Information
Table 32 Meas_Temperature: Resources
Type Used or Modified
Registers R0, R1, R2, R3, R4, R5, R6, R7
SFR ACC, B, CFG0, CFG1, CFG2, DIVIC, DPH, DPL, PSW
Stack 9 Bytes
1)
1) Two additional bytes, not included here, are needed to call the library function
Table 33 Meas_Temperature: Execution Time and Charge Consumption
Parameter Symbol Values Unit Note / Test Condition
Min. Typ. Max.
Execution Time
t
comp
– 668 726 µs DIVIC = 00
H
,
by default 2 ADC measurements are
taken and averaged
Charge Consumption
Q
comp
– 1,2 1,82 µC DIVIC = 00
H
,
by default 2 ADC measurements are
taken and averaged
