2.10.7 Execution Information
2.10.8 Code Example
See Figure 9 “Code example for usage of the functions Start_Supply_Voltage, Trig_Supply_Voltage and
Get_Supply_Voltage()” on Page 68
Table 53 Trig_Supply_Voltage: Execution Time and Charge Consumption
Parameter Symbol Values Unit Note / Test Condition
Min. Typ. Max.
Execution Time
t
DIVIC=0
– 3 4 µs DIVIC = 00
H
t
DIVIC=3
– 192 208 µs DIVIC = 03
H
Charge Consumption Q
DIVIC=0
– 0,005 0,008 µC DIVIC = 00
H
Q
DIVIC=3
– 0,154 0,354 µC DIVIC = 03
H
