Infinity 54000 - Technical Specification

9
TECHNICAL SPECIFICATION
Model 54000
OPERATING RANGE
Bed Height
7” – 30”
Back Rest Angle
0° - 65°
Knee Break Angle
0° - 35°
Additional Manual Leg Lift
Yes, various positions
Trendelenburg / Reverse Trendelenburg
± 12°
WEIGHT
LIMIT
Safe Working Load (SWL)
600 lbs
Max. Patient Weight
550 lbs
WEIGHTS &
DIMENSIONS
Sleeping Surface Dimension
Width x Length
35”-42”-48” x 80”-84””
Caster Size
3”
Weight IN Carton
290 lbs
Weight OUT of Carton
251 lbs
ELECTRICS
Power Supply (V/PH/Hz)
100-240V/1ph/50-60Hz
Power Consumption (Max)
288 W
Number of Motors
4
Protection Class
IPX4
Insulation Class
II Type B
Duty Cycle
Interruption 10%, Max. 2 min./18min.
Battery backup
Included
ENVIRONMENT
Operating Temperature
40°F - 105°F (5°C - 40°C)
Storage Temperature
15°F – 120°F (-10°C - 50°C)
Operation & Storage Humidity
20% - 80%
Operation & Storage Atmospheric Pressure
700 - 1060 hPa
Operation & Storage Altitude
≤ 3000 m
Noise Level
< 50 db(a)
