Infinity Bass Link - Exploded View Legend

LEGEND TO EXPLODED VIEW
BASSLINK (W/REMOTE LEVEL CONTROL)
BASSLINK X
Ref# Part#
Qty
Description
1
700LC150-1 1 BASSLINK LOWER ENCLOSURE 366.5*322*101.5H BLACK ABS
715LC150W 1 BASSLINK X - LOWER ENCLOSURE 366.5*322*101.5H BLACK ABS
2
700TC150-1 1 BASSLINK TOP ENCLOSURE 366.5*322*105.25H BLACK ABS
715LC150X 1 BASSLINK X - TOP ENCLOSURE 366.5*322*105.25H BLACK ABS
3
25PF12FJ-CW01 1 Basslink Woofer 10" 4 ohm
25PF12FJ-CW02 1 Basslink X - Woofer 10" 4 ohm
4
SZ579-1 1 LOGO INFINITY
5
PR-255000 1 Basslink PASSIVE RADIATOR
PR-255002 1 Basslink X - PASSIVE RADIATOR
6
1932M1813 6 MICA ISOLATOR TO-220 18 X 13mm
7
06-T21001 2 SCREW 2 X 10mm P Type
8
06-T30804 4 SELF-TAPPING SCREW 3 x 8mm
9
06-T31004 5 SCREW M3 X 10mm
10
06-T31014 2 SELF-TAPPING SCREW 3 x 10mm P Type
11
06-M30809 2 SCREW M3 x 8 x 0.5 Type C
12
06-T41209 10 SELF-TAPPING SCREW 4 x 12mm P Type
13
06-M31204 6 SCREW M3 X 12mm C Type
14
06-T41403 16 SCREW 4 X 14mm P Type
15
06-T42009 13 SCREW 4 X 20mm
16
06-M31204 4 SCREW M3 X 12mm
17
06-M31603 1 SCREW M3 X 16mm
18
06-N3H01 1 HEXAGON NUTS M3
19
06-T30804 4 SCREW 4 X 8mm
20
06-W03P02 2
FIBER WASHER 3mm x 8mm x 0.3t
21
06-W03P03 3
FIBER WASHER 3mm x 8mm x 0.5t
22
06-W04P01 1
FLAT WASHER 10mm x 4.2mm x 0.8t
23
652M3T03 1 SOLDER TERMINAL M3 t=0.3
24
650IH125 4
IC HOLDER
25
653HS150 2 HEAT SINK 78 x62x2.5t
26
712PS150 1
PCB SPACER 6.3 x 12L
27
700SH150 1 SPACE HOLDER
28
723D150 2 EVA 182.5*18.5*2t
29
723C150 2 EVA 143*10.75*2t
30
723E156 1 EVA 92 x 4 x 1T
31
725B150 1 RUBBER SEAL
32
725C150 1 RUBBER SEAL
33
631PM150-1 1 PUNCH MESH 3*4P*1T BLACK
34
631PM150 1 PUNCH MESH 3*4P*1T BLACK
35
640RP150A-1 1 REAR PANEL 228*143*27*3t
36
650HB150 4 IN HEX-BOLT M5*0.8P*180L
37
650SN150 6
SPEED NUT 16X13X1T SECC 20/20
38
703BV150 2 Basslink BRACKET(V) 255 x 64.5 x 33 x 5T BLACK
703BV150W 2 Basslink X - BRACKET(V) 255 x 64.5 x 33 x 5T WHITE
39
703BH150-1 4 Basslink BRACKET(H) 215.7 x 81 x 33 x 5T BLACK
703BH150W 4 Basslink X - BRACKET(H) 215.7 x 81 x 33 x 5T WHITE
40
723A150A 4 EVA PACKING(A) 9.5*2t
41
723A150 1 RUBBER SEAL 2.5 X 1100L
42 NLA-REPAIR
1
MAIN ASS'Y PCB
43 1010DS150-1 1 AMP-SMD ASS'Y
44 NLA-REPAIR
1
TONE CONTROL PCB ASS'Y
