Infinity Beta SW-12 User Manual

SW-12 120V Electrical parts list
Part number Description Reference Designator
Resistors
021-100398-100 Metal Film Resistor 100R 1/8W F R339
021-100401-020 MOF Resistor 1K 1W J FK TYPE R173
021-100498-100 Metal Film Resistor 1K 1/8W F R363,381
021-100598-100 Metal Film Resistor 10K 1/8W F R338,342,343,346,348,353,
021-100698-100 Metal Film Resistor 100K 1/8W F R383
021-100798-100 Metal Film Resistor 1M 1/8W F R356
021-100898-100 Metal Film Resistor 10M 1/8W F R362
021-110698-100 Metal Film Resistor 110K 1/8W F R347
021-121598-100 Metal Film Resistor 12K1 1/8W F R354,369
021-140598-100 Metal Film Resistor 14K 1/8W F R380
021-150198-100 Metal Film Resistor 1K5 1/8W F R341
021-162398-100 Metal Film Resistor 162R 1/8W F R384
021-220598-100 Metal Film Resistor 22K 1/8W F R382
021-267498-100 Metal Film Resistor 2K67 1/8W F R336
021-340398-100 Metal Film Resistor 340R 1/8W F R357,371
021-357498-100 Metal Film Resistor 3K57 1/8W F R335
021-430498-100 Metal Film Resistor 4K3 1/8W F R204
021-470305-021 MOF Resistor 470R 5W J R78
021-549398-100 Metal Film Resistor 549R 1/8W F R344
021-560305-020 MOF Resistor 560R 5WS J 8x25 R76
021-619498-100 Metal Film Resistor 6K19 1/8W F R359,374
021-620598-100 Metal Film Resistor 62K 1/8W F R214
021-680398-100 Metal Film Resistor 680R 1/8W F R360
021-787398-100 Metal Film Resistor 787R 1/8W F R350,364
021-909398-100 Metal Film Resistor 909R 1/8W F R385
021-931498-100 Metal Film Resistor 9K31 1/8W F R351
022-005105-020 Resistor PN:SQM 0R05 5W J 25x13 R2
024-000097-120 SMD Resistor 0R 1/4W J 1206 R301-303,309,296,297
024-000098-120 SMD Resistor 0R 1/8W J 0805 R8,193
024-000098-120 SMD Resistor 0R 1/8W J 0805 R313,314,318,320
024-100298-120 SMD Resistor 10R 1/8W J 0805 R89,90,140,150
024-100398-121 SMD Resistor 100R 1/4W J 1206 R249
024-100498-120 SMD Resistor 1K 1/8W J 0805 R110
024-100498-120 SMD Resistor 1K 1/8W J 0805 R81,85,96,97,131,137,142,
024-100498-121 SMD Resistor 1K 1/4W J 1206 R238,264
024-100598-101 SMD Resistor 10K 1/4W F 1206 R200B,201B,218B,219B,298
024-100598-120 SMD Resistor 10K 1/8W J 0805 R5,7,16,118,121,122,125,1,
024-100598-120 SMD Resistor 10K 1/8W J 0805 R75,82,83,92,98,132,133,
024-100598-121 SMD Resistor 10K 1/4W J 1206 R202,205-207,212,217,222,
024-100698-101 SMD Resistor 100K 1/8W F 1206 R200,201,218,219
024-100698-120 SMD Resistor 100K 1/8W J 0805 R15,120
024-100798-120 SMD Resistor 1M 1/8W J 0805 R32,33
024-110598-120 SMD Resistor 11K 1/8W J 0805 R187,188,190,191
024-110598-120 SMD Resistor 11K 1/8W J 0805 R74,99
024-120498-120 SMD Resistor 1K2 1/8W J 0805 R189,192
024-130498-100 SMD Resistor 1K3 1/8W F 0805 R119
