Infinity Beta SW-12 User Manual

SW-12 230V Electrical parts list
Part number Description Reference Designator
Resistors
216-0300201-000 MOF Resistor 1K 1W J FK TYPE R173
216-0300201-000 MOF Resistor 470R 5W J (NORMAL SIZE)  R78
216-0300201-000 MOF Resistor 560R 5WS J 8x25 KINK R76
216-0300201-000 Resistor PN:SQM 0R05 5W J 25x13 R2
216-0300201-000 SMD Resistor 0R 1/8W J 0805 R8,193
216-0300201-000 SMD Resistor 1K 1/8W J 0805 R110
216-0300201-000 SMD Resistor 10K 1/8W J 0805 R5,7,16,118,121,122,125,1,
216-0300201-000 SMD Resistor 100K 1/8W J 0805 R15,120
216-0300201-000 SMD Resistor 11K 1/8W J 0805 R187,188,190,191
216-0300201-000 SMD Resistor 1K2 1/8W J 0805 R189,192
216-0300201-000 SMD Resistor 1K3 1/8W F 0805 R119
216-0300201-000 SMD Resistor 15K 1/8W J 0805 R20,21
216-0300201-000 SMD Resistor 16K 1/8W F 0805 R13,13B
216-0300201-000 SMD Resistor 22R 1/8W J 0805 R28,29
216-0300201-000 SMD Resistor 2K2 1/8W J 0805 R17,31
216-0300201-000 SMD Resistor 22K 1/8W J 0805 R127
216-0300201-000 SMD Resistor 3K3 1/8W J 0805 R77,79,22,169
216-0300201-000 SMD Resistor 33K 1/8W J 0805 R4,6,14,60,60B
216-0300201-000 SMD Resistor 4K12 1/8W F 0805 R63
216-0300201-000 SMD Resistor 47R 1/8W J 0805 R24-27
216-0300201-000 SMD Resistor 470R 1/8W J 0805 R145,155,177,186
216-0300201-000 SMD Resistor 47K 1/8W J 0805 R3,171
216-0300201-000 SMD Resistor 5K1 1/8W J 0805 R48A,48B,48C,48D,48E
216-0300201-000 SMD Resistor 5K6 1/8W J 0805 R30
216-0300201-000 SMD Resistor 6K8 1/8W J 0805 R23
216-0300202-000 SMD Resistor 0R 1/8W J 0805 R313,314,318,320
216-0300202-000 SMD Resistor 10R 1/8W J 0805 R89,90,140,150
216-0300202-000 SMD Resistor 1K 1/8W J 0805 R81,85,96,97,131,137,142,
216-0300202-000 SMD Resistor 10K 1/8W J 0805 R75,82,83,92,98,132,133,
216-0300202-000 SMD Resistor 1M 1/8W J 0805 R32,33
216-0300202-000 SMD Resistor 11K 1/8W J 0805 R74,99
216-0300202-000 SMD Resistor 20K 1/8W J 0805 R95,141
216-0300202-000 SMD Resistor 220R 1/8W J 0805 R136,167
216-0300202-000 SMD Resistor 2K2 1/8W J 0805 R134
216-0300202-000 SMD Resistor 22K 1/8W J 0805 R37
216-0300202-000 SMD Resistor 2M2 1/8W J 0805 R87,93
216-0300202-000 SMD Resistor 2K7 1/8W J 0805 R80,84,157
216-0300202-000 SMD Resistor 3K9 1/8W J 0805 R130,161
216-0300202-000 SMD Resistor 39K 1/8W J 0805 R86,94
216-0300202-000 SMD Resistor 470R 1/8W J 0805 R91
216-0300202-000 SMD Resistor 4K7 1/8W J 0805 R151-153,183,34,36
216-0300202-000 SMD Resistor 47K 1/8W J 0805 R35
216-0300202-000 SMD Resistor 56K 1/8W J 0805 R38
216-0300202-000 SMD Resistor 6K8 1/8W J 0805 R135,166
216-0300203-001 Metal Film Resistor 100R 1/8W F R339
216-0300203-001 Metal Film Resistor 1K 1/8W F R363,381
216-0300203-001 Metal Film Resistor 10K 1/8W F R338,342,343,346,348,353,
216-0300203-001 Metal Film Resistor 100K 1/8W F R383
216-0300203-001 Metal Film Resistor 1M 1/8W F R356
216-0300203-001 Metal Film Resistor 10M 1/8W F R362
216-0300203-001 Metal Film Resistor 110K 1/8W F R347
SW-12
15

Infinity Beta SW-12 Specifications

General

Brand	Infinity
Model	Beta SW-12
Category	Subwoofer
Language	English
