Part number Description Reference Designator
072-010058-000 RCA Jack PN:0502000W1G (Red,White) J201
072-040007-000 Connector JS-1001-07 P3,4
072-040008-110 Connector JS-1001-08 P1
072-040008-110 Connector JS-1001-08 P2
072-040039-000 Terminal PC205 (t=0.8m/m) T205MA T1
072-040064-000 Terminal PC250(t=0.8),T250MA T2,TER6
072-040064-000 Terminal PC250(t=0.8),T250MA TER2
072-040096-000 Terminal (t=0.8mm) PC187(0.8) TER5,TER7
072-040096-000 Terminal (t=0.8mm) PC187(0.8) TER1,3,4
072-040229-000 Header Right Angle PN:211-107-000-400 7PIN PIN2
072-040230-000 Header Right Angle PN:211-111-000-400 11PIN PIN1
072-040253-000 Header Right Angle PN:211-103-000-400 3PIN M3
072-040337-000 Header Right Angle PN:211-110-000-400 10PIN M4
072-040338-000 Header Right Angle PN:211-105-000-400 5PIN M3
072-060219-000 Binding Post PN:A807A-RB 8PIN J200
073-010021-000 Screw PN:PCB-2(M3) 4PIN T1,2,3
073-014044-000 Bracket 6.64"x3.50"x3.20" SPCC
073-050001-000 FUSE CLIP P/N:CFFH1206 F1,B1
073-111003-000 Shorting Strap 54.9x13.6x1mm J7
073-111004-000 Shorting Strap 29.5x12.4x0.8m/m J4,9
074-020018-000 Rocker SW PN:RF1003-BB4-0
074-030002-000 Toggle SW PN:L101-T2B4QE SW200-202
074-300018-000 Relay PN:943-1C-48D RLY1
082-022611-000 Wire Set #26 UL1007 L=110mm blk+wht x6 XH7Px2 P3
082-082620-000 Wire Set #26 UL1007 L=200mm XH8Px2 blk/wht P2
086-021836-000 Power Cable SPT-2 #18 +T187
091-000128-000 Fuse T4A/250V φ5x20m/m
181-911800-338 Wire Set #18AWG UL1007 blk L=110mm C211
181-921422-002 Wire Set #14AWG UL1015 Red 625mm SPE+
181-921600-000 BLK Wire #16 UL1015 T187 L:140mm
181-921699-000 WHT Wire #16 UL1015 T187 L:160mm
008-060302-000 Gasket(UL) C4305 25x22x1m/m BLK
008-060302-072 Gasket(UL) PN:MO-48C 25x18 t=5mm
008-061215-000 Gasket C4305 12x15 t=5mm CR
008-062001-000 Gasket CR C4305 196x10mm t=1mm
008-063001-000 Gasket CR C4305 320x10mm t=1mm
042-014107-001 Transformer EI-125 YT-9313-2
043-300101-000 Inductor PN:YT-10033 30uH L9,10
043-324300-000 Inductor 324uH YT-10778 L13
043-560200-000 Inductor 56uH YT-10779 L12
043-700100-000 Inductor 70uHx2 YT-10024 L8
043-820300-000 Inductor 820uH YT-10034 L1
044-100100-000 SMD Ferrite Bead PN:321611 600R/100MHz 1206 FB1,FB2
SW-12
14
