Part number Description Reference Designator
Semiconductors
050-505200-001 LED PN:LT-2402-21 LED1
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 (ON) Q6
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 (ON) Q31
051-005600-100 PNP Transistor PN:MPSW56RLRA TO-92 (ON) Q8
051-222200-100 NPN Transistor PN:MPS2222ARLRA TO-92 Q20,22
051-290700-100 PNP Transistor PN:MPS2907A RLRA TO-92 Q12,14,16,18
051-540101-000 PNP Transistor PN:2N5401 TO-92 Q3
051-555100-000 NPN Transistor PN:2N5551 TO-92 Q21,23
051-640001-000 Mosfet N-Channel PN:IRF640N TO-220 (IR) Q11,13,15,17
052-400080-000 Bridge Regulator PN:RS804 400V,8A BR1
053-211100-000 IC;DIP,Driver PN:IR2111 8PIN (IR) U7,8
053-257400-100 IC;DIP,Regulator PN:LM2574 HVN-15V 8PIN (NS) U6
054-000100-100 SMD Diode PN:ES1D 200V 1A D1,23,37,40,44,47
054-000100-100 SMD Diode PN:ES1D 200V 1A D35,43
054-001002-100 SMD Zener Diode PN:BZX84C10 10V SOT-23 D32
054-001002-100 SMD Zener Diode PN:BZX84C10 10V SOT-23 D42,49
054-001501-100 SMD Zener Diode PN:BZX84C15 15V SOT-23 D2,3
054-005501-100 SMD Zener Diode PN:BZV55C3V6 (PHILIPS) D60
054-007200-100L SMD IC; PN:M072M-TE1 DMP8 (JRC) U9,10
054-007200-100L SMD IC; PN:M072M-TE1 DMP8 (JRC) U200-205,301
054-007400-100 SMD IC;(OP) PN:TL074CDR (TI) U300
054-011400-100 SMD Transistor PN:DTC114TKA SMT3 (ROHM Q202
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 (ON Q25,28,29,37,50,51
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 (ON Q203,204
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 (ON Q26,27,30,36,52
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 (ON Q34,35
054-050601-100 SMD Zener Diode PN:BZX84C5V6 5.6V SOT-23 TAPIN D30
054-050601-100 SMD Zener Diode PN:BZX84C5V6 5.6V SOT-23 TAPIN Z7,8
054-414803-100 SMD Diode PN:LL4148 (Wishay) D4-5,13,14,21,22,31,33,38,
054-414803-100 SMD Diode PN:LL4148 (Wishay) D36,39,46,52,61
054-414803-100 SMD Diode PN:LL4148 (Wishay) D200-205,207,209,212,216,
054-540100-100 SMD Transistor PN:MMBT5401 LT1 SOT-23 Q1
054-540100-100 SMD Transistor PN:MMBT5401 LT1 SOT-23 Q33,40
054-555100-100 SMD Transistor PN:MMBT5551 LT1 (ON) Q2
054-555100-100 SMD Transistor PN:MMBT5551 LT1 (ON) Q32
Miscellaneous
061-001021-000 Knob PN49001-WD7 φ16x14 VR301-303
061-001052-000 Knob PN:49001-W D=15.1 H=14.5 R233,216
061-100016-000 Partition Post PN:BCMS-8 L=8mm Nylon 66(UL)
061-314002-000 Strain Relief P/N SB4F-2 PANEL,COVER
061-700044-000 Mycar 13x18mm TO-220 Q13,17
061-700090-900 Washer 16x21mm t=2mm Q11,15
063-010010-000 Bracket for Power Transistor P/N:TRK-2 Q11,13,15,17,TH1
063-332101-000 Bucket 12.83"x8.33"x3.93" ABS 94V0
063-332108-900 Panel 12.83x8.33" t=.984" SPCC
071-060280-500 Washer 8#-32 8.5 t=3m/m
071-100606-060 Washer PN:WS3-2 OD=6 ID=3.t=2mm Q11,13
SW-12
13
