Infinity Beta SW-12 User Manual

Part number Description Reference Designator
026-500595-254 VR 50KA P/N:RK163111R405-EJ R216
026-500595-267 VR 50KBx4 PN:RD1631411001D-50KBx4 (EJ) R233
Capacitors
031-100184-100 SMD Capacitor 0u01/250V K 0805 X7R C104,119
031-100244-100 SMD Ceramic Capacitor 0u01/50V K 0805 X7R C27,28
031-100244-100 SMD Ceramic Capacitor 0u01/50V K 0805 X7R C108,118,131,140
031-100244-101 SMD Capacitor 0u01/50V K 1206 X7R C12,13,224,280
031-100343-100 SMD Capacitor 100pF/50V J 0805 NPO C81,84
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R C10,69,112,115,135,138
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R C75-78,82,85
031-100344-102L SMD Capacitor 0u1/50V K 1206 X7R C227,229,230,232-235
031-100344-104 SMD Capacitor 100pF/50V K NPO 1206 C204,222
031-100345-300 SMD Capacitor 0u1/50V M 1206 X7R C305,306
031-100384-100R SMD Capacitor 0u1/250V K 1206 X7R C5,6
031-180344-100 SMD Capacitor 0u18/50V K 0805 X7R C80,83
031-220344-103 SMD Capacitor 220pF/50V K NPO 1206 C200,210,215,216
031-220344-300 SMD Capacitor 220pF/50V K 0805 NPO C40
031-330445-100 SMD Capacitor 3300pF/50V M 1206 X7R C281
031-470144-101 SMD Capacitor 0u0047/50V K 0805 X7R C1G1
031-470244-102 SMD Capacitor 0u047/50V K 0805 X7R C93,94,101,124
031-470444-101 SMD Capacitor 4700pF/50V K X7R 1206 C2G1
031-560243-100 SMD Capacitor 56pF/50V J 0805 NPO C92,102,105,125
031-560343-102 SMD Capacitor 560pF/50V J 0805 NPO C79
031-680444-100 SMD Capacitor 6800pF/50V K X7R 1206 C212
032-100484-200 END Mylar Capacitor 1uF/250V K P:15 C37,39,30
033-330444-270 NPE Capacitor 3u3/50V K10 (R)8x13 SBE C114,137
033-680464-270 NPE Capacitor 6u8/100V K10 (R)1020 GNE C113,136
034-100515-300G Electrolytic Capacitor 10uF/16V M (R)0511 P:2 C220
034-100614-300 Electrolytic Capacitor 100uF/16V M (R)0611 P:2.5 C8
034-100615-301 Electrolytic Capacitor 100uF/16V M (R)0611 P:5 C221
034-100625-300 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 C62
034-100625-303 Electrolytic Capacitor 100uF/25V M (R) P:2.5 C117
034-100695-300 Electrolytic Capacitor 100uF/63V M (R)1012 P:5 C142
034-100715-202 Electrolytic Capacitor 1000uF/16V M (R)1017 P:5 C109,132
034-100895-204 Electrolytic Capacitor 10000uF/63V M (R)30x51 C1,4
034-220516-301 Electrolytic Capacitor 22uF/16V M (R)0511 P:2 C223,225
034-220525-300 Electrolytic Capacitor 22uF/25V M (R)5x11 P:2.5 C25,26
034-220525-300 Electrolytic Capacitor 22uF/25V M (R)5x11 P:2.5 C303,304,14,15
034-330615-301 Electrolytic Capacitor 330uF/16V M (R)0812 P:3.5 C32
034-330625-300 Electrolytic Capacitor 330uF/25V M (R)1013 P:5 C11,100
034-470415-300 Electrolytic Capacitor 4u7/50V M (R)0511 P:2.0 C7
035-100363-300 PE Capacitor 0u1/100V J P:5m/m C322,323,328
035-220243-100 PE Capacitor 0u022/63V J P:5m/m C202
035-330293-300 PE Capacitor 0u033/63V J P:5 C209,218
035-330393-300 ESK Mylar Capacitor 0u33/63V J P:5 C207,208
035-680253-300 PE Capacitor 0u068/63V J P:5m/m C201,213,380,381
039-220180-100 Safety Capacitor 18x16.5x8.5mm PN:XG275M224VHS2 CXAC1
SW-12
12
