Infinity Beta SW-12 User Manual

Part number Description Reference Designator
216-0300204-000 ;FR-4 6 63.5x31x1.6mm;(KAPPA/SW12 FUSE
216-0300204-000 INDUCTOR 324uH YT-10778 L13
216-0300204-000 (PCB TYPE) PC250(t=0.8),T250MA TER2
216-0300204-000 T187MA(PCB TYPE) (t=0.8mm) PC187(0.8) TER1,3,4
216-0300204-000 FUSE CLIP P/N:CFFH1206 F1,B1
216-0300204-000 FUSE P/N:S506 T2A/250V 5x20mm
416-0300201-001 () 54.5x38.5x41cm
416-0300201-001 PE 4"x10"x0.08m/m
416-0300201-001 PE 16"x24"x0.08mm
416-0300201-001  13x34cm t=2cm
416-0300201-001  21x34cm t=2cm
416-0300201-001  53x37x20cm
416-0300201-001 () (53x34xP22cm)x4(37x34xP14cm)x4
416-0300201-001 () 53x37cm
416-0300201-001  800x450mm t=1.0mm
316-0300201-001 MODEL 88 GASKET(UL) C4305 25x22x1m/m BLK R233(VR)
316-0300201-001 GASKET (UL) PORON PN:MO-48C 25x18 t=5mm  X'FORMER
316-0300201-001 GASKET C4305 12x15 t=5mm CR  
316-0300201-001 GASKET CR C4305 196x10mm t=1mm  COVER()x2,COVER()x2
316-0300201-001 GASKET CR C4305 320x10mm t=1mm  COVER()x2,COVER()x2
316-0300201-001 Transformer 230V/50Hz EI-125 YT-10145 PT1
316-0300201-001 Knob PN49001-WD7(46077 φ16x14 for VR301-303
316-0300201-001 Knob PN:49001-W (18 )D=15.1 H=14.5 for R233,216
316-0300201-001  PN:BCMS-8 L=8mm NYLON 66(UL) PCB
316-0300201-001 Strain Relief P/N SB4F-2 PANEL,COVER
316-0300201-001 Mylar 13x18mm TO-220 for Q13,17
316-0300201-001 Washer 16x21mm t=2mm for Q11,15
316-0300201-001  (KAPPA1000) 12.83x8.33x3.93"ABS 94V0
316-0300201-001 Bracket for Power Transistor P/N:TRK-2 for Q11,13,15,17,TH1
316-0300201-001 PANEL (SW-12 230V) 12.83x8.33" t=.984" SPCC
316-0300201-001 UL PVC300V 105 φ1mm  (500)
316-0300201-001  PMS-H;M3x10mm  TRx5
316-0300201-001  M3x8mm  PRE PCB
316-0300201-001  #6-32x1/4"  MAIN PCB+
316-0300201-001  #6-32x5/16"  +PANEL
316-0300201-001  8#-32x1/2"  
316-0300201-001  PTS-4;3.5x12mm  BPx2
316-0300201-001  3x8  PCB
316-0300201-001  PTS-4;3x12  RCAx1
316-0300201-001  4x12mm  COVERx4
316-0300201-001  (42-08K) 8#-32  8.5 t=3m/m 
316-0300201-001 Washer PN:WS3-2 OD=6 ID=3.t=2mm  Q11,13
316-0300201-001  (S12P) 6.64"x3.50"x3.20" SPCC 
316-0300201-001 ROCKER SW (POWER) PN:RF1003-BB4-0
316-0300201-001 Wire Set #26 UL1007 L=110mm +x6 XH7Px2 P3
316-0300201-001 Wire Set #26 UL1007 L=200mm XH8Px2 /+CORE P2
316-0300201-001 VDE LF2-75 6 2PIN  T187Fx2
316-0300201-001 UL PVC φ1x5mm  105 Q17,15,13,11x2
316-0300201-001  #18AWG UL1007  L=110mm +7mm C211
316-0300201-001  #14AWG UL1015  625mm T205/T205(t=0.8)+ SPE-
316-0300201-001  #14AWG UL1015  625mm T250/T250+ SPE+
316-0300201-001 BLK #16 UL1015 T187 L:140mm
316-0300201-001 WHT  #16 UL1015 T187 L:160mm
216-0300201-000 ;FR-4 168.5x84x1.6mm(KAPPA/SW12 MB)
