Infinity Beta SW-12 User Manual

Part number Description Reference Designator
216-0300201-000 SMD Capacitor 220pF/50V K 0805 NPO C40
216-0300201-000 SMD Capacitor 0u0047/50V K 0805 X7R C1G1
216-0300201-000 END Mylar Capacitor 1uF/250V K P:15 C37,39,30
216-0300201-000 NPE Capacitor 3u3/50V K10 (R)8x13 SBE C114,137
216-0300201-000 NPE Capacitor 6u8/100V K10 (R)1020 GNE C113,136
216-0300201-000 Electrolytic Capacitor 100uF/16V M (R)0611 P:2.5 C8
216-0300201-000 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 C62
216-0300201-000 Electrolytic Capacitor 100uF/63V M (R)1012 P:5 C142
216-0300201-000 Electrolytic Capacitor 10000uF/63V M (R)35x52 C1,4
216-0300201-000 Electrolytic Capacitor 22uF/25V M (R)5x11 P:2.5 TAPIN C25,26
216-0300201-000 Electrolytic Capacitor 330uF/25V M (R)1013 P:5 C11,100
216-0300201-000 Electrolytic Capacitor 4u7/50V M (R)0511 P:2.0 C7
216-0300202-000 SMD Ceramic Capacitor 0u01/50V K 0805 X7R C108,118,131,140
216-0300202-000 SMD Capacitor 100pF/50V J 0805 NPO C81,84
216-0300202-000 SMD Capacitor 0u1/50V K 0805 X7R C75-78,82,85
216-0300202-000 SMD Capacitor 0u18/50V K 0805 X7R C80,83
216-0300202-000 SMD Capacitor 0u047/50V K 0805 X7R C93,94,101,124
216-0300202-000 SMD Capacitor 56pF/50V J 0805 NPO C92,102,105,125
216-0300202-000 SMD Capacitor 560pF/50V J 0805 NPO C79
216-0300202-000 Electrolytic Capacitor 100uF/25V M (R) P:2.5 C117
216-0300202-000 Electrolytic Capacitor 1000uF/16V M (R)1017 P:5 C109,132
216-0300202-000 Electrolytic Capacitor 330uF/16V M (R)0812 P:3.5  C32
216-0300203-001 SMD Capacitor 0u01/50V K 1206 X7R C12,13,224,280
216-0300203-001 SMD Capacitor 0u1/50V K 1206 X7R C227,229,230,232-235
216-0300203-001 SMD Capacitor 100pF/50V K NPO 1206 C204,222
216-0300203-001 SMD Capacitor 0u1/50V M 1206 X7R C305,306
216-0300203-001 SMD Capacitor 220pF/50V K NPO 1206 C200,210,215,216
216-0300203-001 SMD Capacitor 3300pF/50V M 1206 X7R C281
216-0300203-001 SMD Capacitor 4700pF/50V K X7R 1206 C2G1
216-0300203-001 SMD Capacitor 6800pF/50V K X7R 1206 C212
216-0300203-001 Electrolytic Capacitor 10uF/16V M (R)0511 P:2 C220
216-0300203-001 Electrolytic Capacitor 100uF/16V M (R)0611 P:5 C221
216-0300203-001 Electrolytic Capacitor 22uF/16V M (R)0511 P:2 C223,225
216-0300203-001 Electrolytic Capacitor 22uF/25V M (R)5x11 P:2.5 TAPIN C14,15,303,304
216-0300203-001 PE Capacitor 0u1/100V J P:5m/m C322,323,328
216-0300203-001 PE Capacitor 0u022/63V J P:5m/m C202
216-0300203-001 PE Capacitor 0u033/63V J P:5 C209,218
216-0300203-001 ESK Mylar Capacitor 0u33/63V J P:5 C207,208
216-0300203-001 PE Capacitor 0u068/63V J P:5m/m C201,213,380,381
216-0300204-000 Capacitor 0u22/250V 18x16.5x8.5mm PN:XG275M224VHS2 CXAC1
Semiconductors
216-0300201-000 NPN Transistor PN:MPSW06RLRA TO-92 (ON) Q6
216-0300201-000 PNP Transistor PN:MPSW56RLRA TO-92 (ON) Q8
216-0300201-000 PNP Transistor PN:MPS2907A RLRA TO-92 Q12,14,16,18
216-0300201-000 PNP Transistor PN:2N5401 TO-92 Q3
216-0300201-000 MOSFET N-Channel PN:IRF640N TO-220 (IR) Q11,13,15,17
216-0300201-000 Bridge Regulator PN:RS804 400V,8A BR1
216-0300201-000 IC;DIP,Regulator PN:LM2574 HVN-15V 8PIN (NS) U6
216-0300201-000 SMD DIODE PN:ES1D 200V 1A D1,23,37,40,44,47
216-0300201-000 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 D32
216-0300201-000 SMD ZENER DIODE PN:BZX84C15 15V SOT-23 D2,3
216-0300201-000 SMD NPN Transistor PN:MMBT3904LT1 SOT23 (ON Q25,28,29,37,50,51
