Limiter (yes/no) yes
Max. Output
Power/THD=10%
150w/10
%
P
-max/TH
D
functional Maximum Output Power Maximum THD as a result
of limiting.
Features
Phase Switch (yes/no) yes — functional
Volume pot Taper
(lin/log)
linear — functional
Input Configuration —
Line In
(L,C,R,AC3,Mono)
L,R — functional
Enabled w/Line/Spkr Input Select Switch
Line Outputs (L,C,R) L,R — functional Buffered Output /
Pre-Volume control
Spkr/Hi Level In
(L,C,R,mono)
L,R — functional
Enabled w/Line/Spkr Input Select Switch
Spkr Out: Hi Pass Filter 100 Hz functional
8 ohm Satellite: 6dB/oct
passive xover
Driven from zero ohms
source impedance
Signal-Present LED Yes — — — Bi-Color LED
(green=signal/ red=no
signal)
Signal-Present Input
Freq.
100 Hz functional Nominal 200uF Series Cap on
PCB
Signal-Present Level 35 mV functional 100Hz into Line Input w/
1 ch. driven
Power on Delay time <2 sec. AC Power Applied
Transients/Pops
Turn-on/off Transient 500 mV-peak 2v-pp @ Speaker Outputs AC Line cycled from OFF
to ON or ON to Off
Efficiency
Stand-by Input Power 14 Watts @ nom. line voltage
Power Cons.@rated
power
110 Watts @ nom. line voltage
Efficiency 136% % Relative to rated output
Protection
Short Circuit Protection yes functional Direct short at output
Line
BU120
HTS-20
Fuse Rating 1.0 Amps Type-T or Slo Blo
Line Fuse Rating 2.0 Amps Type-T or Slo Blo
5
Amplifier/Subwoofer BU-120/HTS-20
