Harman Consumer Group, Inc., 8500 Balboa Blvd.,Northridge, CA 91329 USA
www.infinitysystems.com
© 2009 Harman International Industries, Incorporated.All rights reserved.• Part No. REF100.9/120.9SUBOM 3/09
Infinity and Kappa are trademarks of Harman International Industries, Incorporated,registered in the United States
and/or other countries.
SPECIFICATIONS
100.9w 120.9w
10" (250mm) 12" (300mm)
SSI Automotive Subwoofer SSI Automotive Subwoofer
Power Handling (RMS): 350W 350W
Power Handling (Peak): 1400W 1400W
Sensitivity
@
2.83V/1m: 89dB 91dB
Frequency Response: 25Hz – 400Hz 23Hz – 400Hz
Impedance: 2 or 4 ohms (selectable) 2 or 4 ohms (selectable)
Voice-Coil Diameter: 2" (50mm) 2" (50mm)
Mounting Depth: 5-15/16" (150mm) 6-5/16" (160mm)
Overall Diameter: 10-3/4" (273mm) 12-5/8" (320mm)
Cutout Diameter: 9-1/4" (234mm) 11-3/16" (283mm)
A valid serial number is required for warranty coverage.
Features, specifications and appearance are subject to change without notice.
These products are designed for mobile applications and are not intended for connection to the mains.
Declaration of Conformity
We, Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described
in this owner’s manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 3/09
