Infinity Kappa 102a - TR1134 NPN XSTR 40 V;600 Ma SOT

Part# Description
Reference Designator
Qty
MAIN PCB
Miscellaneous
MI1095 Common Mode Inductor GT's
L1
1
MI1136 Kappa 102a Power Transfor T1 1
FH1001 Fuse Holder Right Angle
1
TH1006 NTC THERMISTOR 10Kohm @
TH1
1
TE1178 Faston Female 0.032" x 0.
CLIP1-4
4
SA0000030 Ferrite Bead (CC1028)
FB9,10
2
BR1345 BUS BAR COPPER 6-TERMINAL BB5,6 2
BR1369 Bus Bar Copper 7 Term. 63 BB1 1
BR1372 Bus Bar 2 Terminals 1000 BB2,3,4 3
CC1028 Ferrite Bead FB1-8 8
CO1315 Power Connector Pin Gold POWER 1
CO1316 Speaker Connector Pin Gold SPEAKER 1
CO1318 RCA Jack Dual Separate Gn INPUT, AUX OUT 2
MI1100 Inductor Air Core 0.38uH
L2,3
2
LAMP MODULE
HA1000 Harness Xover-Lamp Mod. K
XOVER TO LAMP
1
CO1331 Header Right Angle 3-Pos
CONN1,2
2
LA1028 Pilot Lamp 0 3mm. 14v @ 4
LAMP1-8
8
XX1140 Filter Green for 0 3mm. L
LAMP2,4,5,7
4
XX1268 Filter Orange; 3.0mm Lamp
LAMP1,3,6,8
4
RS1705 SMD RES 4.7Kohm 5% 1/8W
R1,2
2
DI1132 SMD Diode Swch LL-34 Pkg
D1,2
2
TR1134 NPN XSTR 40V/600mA SOT-89 PXT2222A
Q1,2
2
SAFEBASS MODULE
Resistors
RS1790 SMD RES 2.7Kohm 5% 1/8W
R3,6
2
RS1962 SMD RES 62Kohm 5% 1/8W
R2,5
2
RS2083 Pot. Carbon 2Kohm 20% Lin
VR1A,VR1C
2
RS2085 Pot Carbon 200Kohm 20% Li
VR1B,VR1D
2
RS2286 Pot Carbon 500 ohm 20% Li
VR2A,VR2B
2
RS2308 SMD RES 620 ohm 5% 1/8W
R1,4
2
Capacitors
CP1177 Cap Poly Film 0.22uF 5% 6
C2,4
2
CP1426 SMD CAP 0.1uF 20% 50V Z5U
C5,6
2
CP1625 Cap Poly Film 0.47uF 5% 6
C1,3
2
Semiconductors
IC1041 IC SMD Dual Op-Amp J-FET-TL072
IC1
1
Miscellaneous
CO1267 CONNECTOR HEADER R/A 2-P
HD2,3
CO1279 CONNECTOR HEADER R/A 3-P
HD1
WA1082 Washer Plain Nylon OD=0.2
XX1264 Shaft 4-Gang Anodized
CO1280 CONNECTOR HEADER R/A 4-P
MISC/MECHANICAL
WA1087 WASHER FELT MATERIAL
14
Kappa 102a
