Infinity Kappa 102a - Kappa 102 a Specifications

Kappa 102a Specifications
POWE
R
4 OHM 2X100
2 OHM 2X150
BRIDGE 4 OHM 300
1 OHM STABLE
PROTECTS
FREQUENCY RESPONSE (+0 -3dB) 20-20KHz
EQUALIZATION
FIXED AT 40Hz Q=1 +11dB
SAFE BASE (DBO) var.freq and Q Yes
CROSSOVE
R
FLAT/LOW/HIGH PASS SWITCH 1
DECADE SWITCH
( 40-320 & 250-2KHz)
VAR. CONTROL 1
SLOPE 12
AUX HIGH PASS OUTPUT WITH SWITCH 1
SUB WOOFER INPUT SELECT
DC COUPLED INPUT
FULL DIFFERENTIAL INPUT
>100K IMP Yes
BRIDGEABLE Yes
V
ARIABLE INPU
T
250mV- 9volts Yes
SPKR/LINE LEVEL SWITCH
REMOTE POWER LED Yes
CHANNEL PROTECT LED Yes
POWER FUSE
(ATC) Yes
THD + NOISE
4 ohm 0.05%
2 ohm 0.10%
bridge 4 ohm 0.10%
SIGNAL TO NOISE
(A Weighted Referenced to Full
Power)
>95dB
CHANNEL SEPARATION
(100 TO 20KHz) >50dB
DAMPING FACTO
R
>202
TURN ON TIME 3 SEC
DC OFFSET <50 mv
A LINE REJECTION
OPERATING VOLTAGE 10 -16vdc
REMOTE ON CURRENT <2ma
QUIESCENT CURRENT <2 AMP
MAX CURREN
T
40
PROTECTION auto reset
spkr short Yes
spkr to ground Yes
thermal Yes
over voltage 18vdc
under voltage 8vdc
All tests to be done from 20 to 20KHz at 14.4 VDC into 4 ohm loads, unless otherwise specified. All
measurements will be done using an Audio Precision System One and the 22KHz filter.
2
Kappa 102a
