Part# Description
Reference Designator
Qty
MAIN PCB
Resistors
RS1700 SMD RES 1Kohm 5% 1/8W
R40,42,43
3
RS1701 SMD RES 10Kohm 5% 1/8W
R27-29,31,39,41,71-73
9
RS1702 SMD RES 100Kohm 5% 1/8W
R30
1
RS1703 SMD RES 2.2Kohm 5% 1/8W
R34,52
2
RS1704 SMD RES 22Kohm 5% 1/8W
R74
1
RS1705 SMD RES 4.7Kohm 5% 1/8W
R25,26,37,75,76
4
RS1706 SMD RES 47Kohm 5% 1/8W
R32,33,38
3
RS1714 SMD RES 8.2Kohm 5% 1/8W
R55,56
2
RS1717 SMD RES 100 ohm 5% 1/8W
R1-6
6
RS1725 SMD RES 15Kohm 5% 1/8W
R69,70
2
RS1831 SMD RES 7.5Kohm 5% 1/8W
R45,47
2
RS1868 RES CER 0.1 ohm 5% 5W
R9,11,13,15,17,20,22,24
8
RS1871 SMD RES 5.1Kohm 5% 1/8W
R46,48
2
RS1878 SMD RES 10 ohm 5% 1/8W
R53,54
2
RS1898 SMD RES 10Kohm 1% 1/8W
R61,67
2
RS1902 RES C/F 33 ohm 5% 1/4W
R8,18
2
RS1916 RES C/F 5.1 ohm 5% 1/4W
R7,10,12,14,16,19,21,23
8
RS1946 SMD RES 49.9Kohm 1% 1/8W
R62,63,44,57
4
RS1957 SMD RES 4.99Kohm 1% 1/8W
R60,66
2
RS2113 SMD RES 24.9Kohm 1% 1/8W
R58,59,64,65
4
Capacitors
CP1126 CAP POLY FILM 1uF 10% 50V
C3
1
CP1355 Cap Alum El. 2200uF 20% 2
C1,2
2
CP1412 Cap Alum El. 47uF 20% 16v
C14
1
CP1415 Cap Alum El. 2.2uF 20% 50
C34,35,37,38
4
CP1417 Cap Alum El. 22uF 20% 16
C26-29
4
CP1426 SMD CAP 0.1uF 20% 50V Z5U
C8-11,13,16-18,20-23,39-42,47-51
21
CP1545 CAP ALUM ELECT 4700uF 20%
C4,5
2
CP1562 Cap Alum El. 330uF 20% 16
C19
1
CP1624 Cap. Alum. El. 2200uF,20% C6,7 2
CP1631 Cap. Alum El 220uF 20% 35
C24,25
2
CP1475 SMD Cap 33pF 5% 50v NPO 1
C30-33
4
CP1496 SMD CAP 100pF 10% 50V X7R
C43-46
4
CP1520 SMD CAP. .01uF 10% 50V T/
C36
1
CP1552 SMD Cap .1uF 20% 100v Z5U
C12,15
2
Semiconductors
DI1010 Diode Fast Rect. 1A/100v
D5-8
4
DI1005 Rectifier Diode 3A/200V
D1,2
2
DI1053 Rect Dual Comm Cathd. 16A
D3
1
DI1054 Rect Dual Comm Anode 16A
D4
1
DI1132 SMD Diode Swch LL-34 Pkg
D9,10,12,14-16
6
DI1167 SMD Zener 16v 5% CP Pkg.
Z1,2
2
IC1041 IC SMD Dual Op-Amp J-FET-TL072
IC1,2
2
TR1108 SMD Xstr NPN 50V/150mA 2SC4936
Q27,31
2
TR1125 SMD Xstr PNP 50V/150mA 2SA1781
Q24,28,32
3
TR1131 SMD Xstr NPN 50v/100mA 2SC5839
Q23
1
TR1209 SMD Xstr 80v/50mA SOT23/S 2SC3906
Q14,22
2
TR1063 NPN Xstr 40v/600mA TO-92 MPS2222A
Q13,21
2
FE100440112 FET Pwr 60v/35A/28mohm IRFZ44
Q1-6
6
TR1057 NPN Pwr Xstr 25A/100V TIP35C
Q7,8,15,16
4
TR1061 PNP Pwr Xstr 25A/100V TIP36C
Q10,11,18,19
4
TR1183 NPN Pwr Xstr 3A/100v/40W TIP31C
Q9,17,26
3
TR1184 PNP Pwr Xstr 3A/100v/40W TIP32C
Q12,20,25
3
13
Kappa 102a
