Infinity Kappa 102a - Page 13

Part# Description
Reference Designator
Qty
PREAMP/DRIVER MODULE
Capacitors
CP1411 Cap Alum El. 100uF 20% 16
C34,35
2
CP1412 Cap Alum El. 47uF 20% 16v
C27,28,33,42
4
CP1417 Cap Alum El. 22uF 20% 16
C25,31
2
CP1426 SMD CAP 0.1uF 20% 50V Z5U
C4,5,10,11,21,22,29,30,36,37-39
12
CP1475 SMD Cap 33pF 5% 50v NPO 1
C3,6,12,13,16,17,26,32,40,41
10
CP1496 SMD CAP 100pF 10% 50V X7R
C7,18
2
CP1520 SMD CAP. .01uF 10% 50V T/
C2,15,23,24
4
CP1557 SMD Cap 56pF 5% 50v NPO
C8,9,19,20
4
CP1563 SMD Cap 150pF 5% 50v NPO
C1,14
2
Semiconductors
DI1132 SMD Diode Swch LL-34 Pkg
D1,2
2
IC1175 IC High Performance Dual Op-Amp NJM5532
IC1,2,3
3
TR1108 SMD Xstr NPN 50V/150mA 2SC4936
Q2,7
2
TR1125 SMD Xstr PNP 50V/150mA 2SA1781
Q3,8
2
TR1131 SMD Xstr NPN 50v/100mA 2SC5839
Q1,6
2
TR1167 NPN Xstr 160v/600mA TO-92 2N5551
Q5,10
2
Miscellaneous
CO1248 CONNECTOR HEADER R/A 6-P
HD3
1
CO1267 CONNECTOR HEADER R/A 2-P
HD2
1
CO1279 CONNECTOR HEADER R/A 3-P
HD1
1
CO1280 CONNECTOR HEADER R/A 4-P
HD4
1
SW1072 Switch Slide 2P2T Horizon
SW1
1
WA1082 Washer Plain Nylon OD=0.2 for VR1 1
XX1264 Shaft 4-Gang Anodized for VR1 1
LP/HP FILTER
Resistors
RS1701 SMD RES 10Kohm 5% 1/8W
R1-7,12-18,22,23
16
RS1702 SMD RES 100Kohm 5% 1/8W
R20,21
2
RS1703 SMD RES 2.2Kohm 5% 1/8W
R8-11
4
RS1779 SMD RES ZERO ohm 5% 1/8W JUMPER
J1-4
4
RS2084 Pot Carbon 20Kohm 20% Lin
VR
1
Capacitors
CP1177 Cap Poly Film 0.22uF 5% 6
C1,2,9,10
4
CP1426 SMD CAP 0.1uF 20% 50V Z5U
C5,6,7,8
4
Semiconductors
IC1041 IC SMD Dual Op-Amp J-FET-TL072
IC3
1
IC1162 IC SMD Quad-J Fet TL074
IC1,2
2
Miscellaneous
CO1247 CONNECTOR HEADER R/A 8-P
HD3
1
CO1267 CONNECTOR HEADER R/A 2-P
HD4
1
CO1279 CONNECTOR HEADER R/A 3-P
HD1
1
CO1280 CONNECTOR HEADER R/A 4-P
HD2
1
CO1304 Header Stght 2-Pos 0.079"
CONN1
1
SW1073 Switch Slide 2P3T Horizon
SW2,3
2
WA1082 Washer Plain Nylon OD=0.2
VR
1
XX1264 Shaft 4-Gang Anodized
VR
1
12
Kappa 102a
