Infinity Kappa 102a - Electrical Parts List

KAPPA 102A Electrical Parts List
Part# Description
Reference Designator
Qty
PWM MODULE
Resistors
RS1700 SMD RES 1Kohm 5% 1/8W
R2,15,18
3
RS1701 SMD RES 10Kohm 5% 1/8W
R9,11
2
RS1702 SMD RES 100Kohm 5% 1/8W
R5
1
RS1703 SMD RES 2.2Kohm 5% 1/8W
R8
1
RS1705 SMD RES 4.7Kohm 5% 1/8W
R6,19
2
RS1709 SMD RES 680 ohm 5% 1/8W
R10
1
RS1710 SMD RES 3.3Kohm 5% 1/8W
R23
1
RS1711 SMD RES 220 ohm 5% 1/8W
R14
1
RS1717 SMD RES 100 ohm 5% 1/8W
R16,17
2
RS1724 SMD RES 6.8Kohm 5% 1/8W
R4
1
RS1733 SMD RES 510 ohm 5% 1/8W
R3
1
RS1783 SMD RES 12Kohm 5% 1/8W
R7
1
RS1826 SMD RES 27 ohm 5% 1/8W
R12,13
2
RS1878 SMD RES 10 ohm 5% 1/8W
R1
1
Capacitors
CP1426 SMD CAP 0.1uF 20% 50V Z5U
C2,3,4,5,10
5
CP1434 SMD Cap 2.7nF 10% 100v X7 C1 1
CP1562 Cap Alum El. 330uF 20% 16 C6 1
CP1565 Cap Alum El. 22uF 20% 10v C19 1
Semiconductors
IC1002 PWN Control Mod. 16 PIN D IC1 1
TY1000 SCR TO-92 Package T/R
SCR1
1
DI1132 SMD Diode Swch LL-34 Pkg D1 1
TR1108 SMD Xstr NPN 50V/150mA CP Q2 1
TR1134 NPN XSTR 40V/600mA SOT-89 Q3,4 2
TR1135 PNP XSTR 60V/600MA SOT-89 Q1,5,6 3
Miscellaneous
CO1249 CONNECTOR HEADER R/A 5-P P1 1
CO1267 CONNECTOR HEADER R/A 2-P P2,3,4 3
HA1001 Harness PWM-Lamp KA102a/K RED (+) 1
PREAMP/DRIVER MODULE
Resistors
RS1700 SMD RES 1Kohm 5% 1/8W
R3,12,23,32
4
RS1701 SMD RES 10Kohm 5% 1/8W
R4,18,19,24,38,39,44,46,49
9
RS1703 SMD RES 2.2Kohm 5% 1/8W
R10,11,30,31,52,53
6
RS1705 SMD RES 4.7Kohm 5% 1/8W
R2,22
2
RS1706 SMD RES 47Kohm 5% 1/8W
R41
1
RS1717 SMD RES 100 ohm 5% 1/8W
R17,20,37,40
4
RS1721 SMD RES 2 Kohm 5% 1/8W
R43,45,48,50
4
RS1722 SMD RES 470 ohm 5% 1/8W
R15,16,35,36
4
RS1725 SMD RES 15Kohm 5% 1/8W
R6,9,26,29
4
RS1783 SMD RES 12Kohm 5% 1/8W
R51
1
RS1831 SMD RES 7.5Kohm 5% 1/8W
R7,8,27,28
4
RS1912 SMD RES 11Kohm 5% 1/8W
R1,21
2
RS1983 SMD RES 560 ohm 5% 1/8W
R42,47
2
RS2090 Pot. 20Kohm 20% Cermet Li VR1 1
11
Kappa 102a
