ELECTRICAL PARTS LIST (Cont.)
Part# Reference Designator Qty Description
PCB, EMI FILTER
DB0009 D5 1 RECT, 6A 400V BRIDGE
CF0057 C1,C2 2 CAP, FX .22UF 250V 10%
RC0004 R23 1 RES, CF 1M0 1/4W 5%
540124 L1 1 IND, CM CHOKE YT7271
KV0001 Z4 1 VARISTOR, 275V 100J .6W
480007 J5,J6,J8 3 SUB, #18B 4 187X032/1/4 STRP
480029 J7 1 SUB, #18R 4 187X032/1/4STRP
PCB, VOLUME MODULUS RIGHT
DL0014 D1,D2 2 LED, 3MM BICOLOR RED/GR
RP0097 R1 1 POT, A10K SINGLE/BRKT D SHAFT
JH0006 J1 1 CNCTR, HEADER 4PIN .100CTR
JC0169A 1 CNCTR, FEM-MA HARNESS 4PSH 15
USED ON LOCATION J1
RP0103 1 POT, KNOB LEVEL R
PCB, INPUT HI LEVEL BAL/OPT
RM0011 R5,R6,R7,R8 4 RES, MF 100K 1/4W 1%
RX0001 R3,R4 2 RES, MO 1K 1W 5%
RX0098 R1,R2 2 RES, MO 510R 2W 5%
CE0137 C1,C2 2 CAP, E 470UF 100V BP 18X42
JC0070 J1 1 CNCTR, 8PIN SPKR JACK RTANG
JH0028 J3 1 CNCTR, HEADER 3PIN .100CTR
RABOS Board
SEMICONDUCTORS
UA0009 U1 1 OPAMP, QUAD 14P DIL TL074/084
UA0010 U2 1 OPAMP, DUAL 8PIN DIL TL082
RESISTORS
RM0001 R24,R25,R33 3 RES, MF 1K00 1/4W 1%
RM0002 R1,R2,R4,R9,R14,R15,R21,R23 8 RES, MF 10K0 1/4W 1%
RM0003 R8,R13 2 RES, MF 15K0 1/4W 1%
RM0012 R3 1 RES, MF 100R 1/4W 1%
RM0013 R34 1 RES, MF 11K0 1/4W 1%
RM0024 R22 1 RES, MF 2K21 1/4W 1%
RM0042 R26 1 RES, MF 681R 1/4W 1%
RM0073 R30 1 RES, MF 392R 1/4W 1%
RM0080 R5,R10 2 RES, MF 825R 1/4W 1%
RM0179 R32 1 RES, MF 66K5 1/4W 1%
RM0260 R36 1 RES, MF 1M0 1/4W 1%
RM0271 R19 1 RES, MF 110K 1/4W 1%
