ELECTRICAL PARTS LIST (Cont.)
Part# Reference Designator Qty Description
RM0281 R7,R12 2 RES, MF 6K04 1/4W 1%
RM0304 R35 1 RES, MF 7K87 1/4W 1%
RM0315 R17 1 RES, MF 2K67 1/4W 1%
RM0321 R31 1 RES, MF 1K27 1/4W 1%
RM0369 R6,R11 2 RES, MF 340R 1/4W 1%
RM0370 R18 1 RES, MF 9K31 1/4W 1%
RM0377 R16 1 RES, MF 3K57 1/4W 1%
RM0378 R20 1 RES, MF 549R 1/4W 1%
RP0087 R27,R29 2 POT, A10K DUAL 12MM HOR 5%
RP0088 R28 1 POT, C10K DUAL -10% MID 1.5K
CAPACITORS
CF0045 C1,C2,C5 3 CAP, F .1UF 63DC 5% 5MMLS
CF0125 C3 1 CAP, F .068UF 100V 5% 5MMLS
CF0135 C4 1 CAP, F .18UF 50V 5% 5MMLS
Miscellaneous
JH0074 J1 1 CNCTR, HEADER 8PIN LOCKING .1C
MISCELLANEOUS
480121 1 SUB, #16B 30 205X032/205X032
SPEAKER WIRE
480122 1 SUB, #16R 30 250X032/250X032
SPEAKER WIRE
810056 7 MET, HTSNK CLIP .9X.5X.2 FET 3PER
USED ON D1,D3,Q1 ON MAIN BOARD;
4PER USED ON Q3,Q4,Q7,Q8 ON
LINEAR BOARD
810066 2 MET, HTSNK CLIP HPS SERIES USED
Q4,Q5 ON MAIN BOARD
810091 1 MET, HTSNK SEC 3FET RP5 USED ON
600078
810092 1 MET, HTSNK PRI 2FET RP5 USED ON
600078
930050 1 CUP, AMP BUCKET
FH0012 1 FUSE, HOLDER PANEL MT SEALED
FS0022 1 FUSE, 3A 250V 1.25X.25 GLASS
HS0004 5 SCREW, #6-32X1/4 PAN PHIL ZNP
1PER USED ON MZ0003; 4PER USED
ON MM0025
HS0062 7 SCREW, #6-1/2 TYPE B PP BLK USED
ON FETS
HS0065 1 SCREW, #6-32X1/4 PAN PHIL BLK
USED ON MZ0003
