4 Inflate the seat pad section of the child seat in the same way
as the adult seat.
5 To inflate the backrest section, use the nozzle that fits inside
the non-return valve. Push the nozzle all the way in, inflate and
then remove the nozzle. After inflation close the non-return valve
cap securely.
6 To fit the seats, attach to the kayak floor using the Velcro strips
running lengthways as shown in the illustration. Suggested seat
configurations can be found in section 6.5.
7 Once the seats are attached to the floor, clip the seat straps
into the appropriate D-ring attachment point on the sides of the
6. GETTING STARTED
Clip straps into D-rings
on side of kayak
Footrest
Ensure seats face
the front of the kayak
Odyssey 375 and
Odyssey 295
Inflating
backrest part
Twist valve
Non-return
valve
Backrest section
Seat pad section
Child inflatable seat
Pump nozzle for
non-return valve
Outside Diameter = 5mm
or 3/16”
