Infinity PRELUDE MTS User Manual

TOGGLE SWITCH
VIEWING CUP IN BOTTOM
OF SPEAKER TOWER
High
Pass
Full
Range
Full
Range
High
Pass
– Set Toggle Switch in tower cup in bottom to the
“Full Range”position,unless you are connecting your system
using Method 1 or Method 4 as shown on page 8 and page 10.
VIEWING CUP IN BOTTOM
OF SPEAKER TOWER
High
Pass
Full
Range
ALIGNMENT
PINS
VIEWING CUP IN BOTTOM
OF SPEAKER TOWER
High
Pass
Full
Range
DOUBLE-ENDED
BANANA PLUG
STEP 4
– Screw alignment pins into cup in bottom of tower,
using two per tower.Screw threaded ends into holes and tighten
until snug.DO NOT overtighten.
STEP 5
– Insert double-ended Audio Banana Plug into tower
as shown.
STEP 6
SUBWOOFER
TOP-FRONT
VIEW
METAL
BRACKET
( ) 10-32
MACHINE SCREWS
4
PHILLIPS
– Add metal bracket,positioning as shown; replace
the four existing screws with four machine,10-32 Phillips head
screws provided.
STEP 3
4
PRELUDE MTS
