Infinity PS-12 Service Manual

Part Number Description Qty Reference Designator
024-470398-120 SMD Resistor 470R 1/8W J 0805 3 R76,99,100
024-470498-120 SMD Resistor 4K7 1/8W J 0805 2 R85,86
024-470598-120 SMD Resistor 47K 1/8W J 0805 4 R44,47,49,107
024-470698-120 SMD Resistor 470K 1/8W J 0805 1 R70
024-470798-120 SMD Resistor 4M7 1/8W J 0805 1 R60
024-510398-120 SMD Resistor 510R 1/8W J 0805 1 R57
024-560598-120 SMD Resistor 56K 1/8W J 0805 1 R122
024-562398-100 SMD Resistor 562R 1/8W F 0805 1 R5A
024-620398-100 SMD Resistor 620R 1/8W F 0805 2 R16,18
024-680498-120 SMD Resistor 6K8 1/8W J 0805 6 R46,91,40-43
024-680598-120 SMD Resistor 68K 1/8W J 0805 6 R33,34A,31,50,52,66
024-768398-100 SMD Resistor 768R 1/8W F 0805 1 R2A
024-820598-120 SMD Resistor 82K 1/8W J 0805 1 R69
024-909598-100 SMD Resistor 90K9 1/8W F 0805 1 R4A
024-910398-100 SMD Resistor 910R 1/8W F 0805 TPAING 1 R110
025-010300-000 Thermister TSE-103 K L:50mm 1
026-200595-269 VR FREQUENCY PN:RD163121R03D-20KBx2(EJ) 1 VR2
026-500495-252 VR 5KA LEVEL PN:RK163111R52B-5KA (EJ) 1 VR1
Capacitors
031-100244-100 SMD Ceramic Capacitor 0u01/50V K 0805 X7R 7 C33,45,51,66,67,5,10
031-100343-100 SMD Capacitor 100pF/50V J 0805 NPO 3 C16,36,58
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R 12 C11,42-44,46-49,52,54,55,60
031-100384-100
R
SMD Capacitor 0u1/250V K 1206 X7R 2 C3,7
031-220243-103 SMD Capacitor 0u022/50V J 0805 X7R 1 C40
031-220344-100 SMD Capacitor 220pF/50V J 0805 NPO 5 C14,15,20,21,19
031-330444-300 SMD Capacitor 3300pF/50V K 0805 X7R 1 C34
031-470244-102 SMD Capacitor 0u047/50V K 0805 X7R 2 C62,59
031-560243-100 SMD Capacitor 56pF/50V J 0805 NPO 2 C57,61
031-560343-102 SMD Capacitor 560pF/50V J 0805 NPO 1 C56
032-100484-200 Mylar Capacitor 1uF/250V K P:15 2 C70,C70B
032-330363-200 Mylar Capacitor 0u33/100V J P:10 (R) 1 C29
032-820244-200 Mylar Capacitor 0u082/100V K (R) 1 C30
033-470464-270 NPE Capacitor 4u7/100V K10 (R)1015 GNE 1 C73
033-680464-270 NPE Capacitor 6u8/100V K10 (R)1020 GNE 1 C72
034-100525-300 Electrolytic Capacitor 10uF/25V M (R)0511 P:5 1 C35
034-100625-300 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 1 C64
034-220525-301 Electrolytic Capacitor 22uF/25V M (R)5x11 P:5 5 C4,9,41,50,53
034-220615-301 Electrolytic Capacitor 220uF/16V M (R)0611 P:5 1 C37
034-330515-000 Electrolytic Capacitor 33uF/16V M (R)0511 P:5 1 C39
034-330525-300 Electrolytic Capacitor 33uF/25V M (R)0511 P:5 1 C1
034-330615-300 Electrolytic Capacitor 330uF/16V M (R)0812 P:5 2 C12,78
034-330780-300 Electrolytic Capacitor 3300uF/80V M (R)22x48 2 C6,8
034-470415-301 Electrolytic Capacitor 4u7/50V M (R)0511 P:5 1 C2
22
PS-10/PS-12
