Infinity PS-12 Service Manual

Part Number Description Qty Reference Designator
034-470615-301 Electrolytic Capacitor 470uF/16V M (R)0812 P:5 1 C65
035-100393-301 Mylar Capacitor 0u1/63V J P:5 2 C28,2A
035-220393-300 PE Capacitor 0u22/63V J P:5 1 C27
035-470293-300 PE Capacitor 0u047/63V J P:5 1 C1A
035-470353-301 ESK Capacitor 0u47/63V J P:5m/m 2 C25,26
038-100363-300 MPE Capacitor 0u1/100V J 2 C68,69
039-100390-100 Safety Capacitor 0u1/275V PN:XG275M104VSL7 1
Semiconductors
050-505200-001 LED PN:LT-2402-21 1
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 (ON) 2 Q2,Q16
051-003100-000 NPN Transistor PN:TIP 31C TO-220 (MOSPEC) 1 Q4
051-005600-100 PNP Transistor PN:MPSW56RLRA TO-92 (ON) 1 Q3
051-222200-100 NPN Transistor PN:MPS2222ARLRA TO-92 1 Q21
051-290700-100 PNP Transistor PN:MPS2907A RLRA TO-92 2 Q19,23
051-540101-000 PNP Transistor PN:2N5401 TO-92 1 Q1
051-555100-000 NPN Transistor PN:2N5551 TO-92 1 Q17
051-640001-000 MOSFET N-Channel PN:IRF640N TO-220 (IR) 2 Q18,22
052-400080-000 Bridge Regulator PN:RS804 400V,8A 1 BR1
053-211100-000 IC;DIP, Driver PN:IR2111 8PIN (IR) 1 U7
054-000100-100 SMD DIODE PN:ES1D 200V 1A 5 D5,26,29,33,38
054-001002-100 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 1 D35
054-001501-100 SMD ZENER DIODE PN:BZX84C15 15V SOT-23 3 D6,7,9
054-007200-100 SMD IC PN:TL072CDR SO-8 (TI) 2 U5,6
054-007400-100 SMD IC;(OP) PN:TL074CDR (TI) 2 U2,3
054-011400-100 SMD Transistor PN:DTC114TKA SMT3 (ROHM 1 Q7
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 (ON 7 Q11,14,13,5,8,25,9
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 (ON 4 Q6,10,12,15
054-045580-100 SMD IC;(OP) PN:NJM4558M-TE3 DMP-8 1 U4
054-050601-100 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 3 D24,36,37
054-414803-100 SMD DIODE PN:LL4148 (Wishay) 12 D1-4,8,27,28,30-32,34,39,
054-540100-100 SMD Transistor PN:MMBT5401 LT1 SOT-23 3 Q20,24,26
Miscellaneous
061-020000-000 Knob ABS φ20x15m/m UL94V-0 BLK 2
061-314002-000 Strain Relief P/N SB4F-2 1
061-400014-000 Rubber Foot ID:6.2 OD:11.5 t=2mm BLK 1
061-700044-000 Mycar 13x18mm TO-220 1
063-010012-000 Bracket - Power Transistor P/N:TRK-1 1
063-321101-000 Plate 322x105.7x15mm BLK ABS-94V0 1
063-531808-000 Bucket 322x105.7x146.5mm BLK (94VO) 1
065-100200-000 UL Sleeve φ2.5 F32-2.5 125 1
071-100608-100 Fiber Washer OD=8mm ID=3.2 t=1 (red) 1
23
PS-10/PS-12
