Part Number Qty Description Reference Designator
051-005600-100ZR 1 GR Transistor PNP MPSW56RLRAR TO-92 (ON) Q3
051-540101-000ZR 1 GR Transistor PNP(FAIRCHILD 2N5401 TO-92 Q1
051-555100-000ZR 1 GR Transistor NPN 2N5551 TO-92 Q17
052-400080-000ZR 1 GR Bridge Rectifier RS804 400V,8A BR1
053-211100-000ZR 1 IC, IR2111 HALF-BRIDGE DRIVER U7
050-505200-001ZS 1 GS LED LT-2402-21
D1A,B NOTE THIS PART IS MISSING
FROM EARLY VERSIONS
051-003100-000ZS 1 GS Transistor NPN TIP 31C TO-220 (MOSPEC) Q4
051-640001-000ZR 2 GR MOSFET N-Channel IRF640NPBF TO-220 (IR) Q18,22
Resistors
024-100298-120ZS 2 GS SMD Resistor 10R 1/8W J 0805 R81,82
024-100398-120ZS 1 GS SMD Resistor 100R 1/8W J 0805 R62
024-100498-100ZS 1 GS SMD 1K 1/8W F 0805 R110
024-100498-120ZS 7 GS SMD 1K 1/8W J 0805 R79,83,92,95,96,105,65
024-100598-120ZS 29 GS SMD 10K 1/8W J 0805
R2,17,19,37,54,58,63,71,72,74,75,84,88,89,
97,106,113-117,111,123,124,119,120,
138,139,141,
024-100698-120ZS 2 GS SMD 100K 1/8W J 0805 R3,112
024-100898-120ZS 1 GS SMD 10M 1/8W J 0805 R121
024-110498-120ZS 1 GS SMD 1K1 1/8W J 0805 R2A
024-110598-100ZS 1 GS SMD 11K 1/8W F 0805 R98
024-110698-100ZS 1 GS SMD 110K 1/8W F 0805 R4A
024-133598-100ZS 1 GS SMD 13K3 1/8W F 0805 R35A
024-137698-100ZS 1 GS SMD 137K 1/8W F 0805 R32
024-160398-120ZS 1 GS SMD 160R 1/8W J 0805 R6A
024-162598-100ZS 1 GS SMD 16K2 1/8W F 0805 R39
024-178498-100ZS 1 GS SMD 1K78 1/8W F 0805 R38
024-180598-100ZS 1 GS SMD 18K 1/8W F 0805 R29
024-187698-100ZS 1 GS SMD 187K 1/8W F 0805 R45
024-200498-120ZS 1 GS SMD 2K 1/8W J 0805 R108
024-200598-120ZS 1 GS SMD 20K 1/8W J 0805 R94
024-220398-120ZS 1 GS SMD 220R 1/8W J 0805 R90
024-220498-121ZS 4 GS SMD 2K2 1/8W J 0805 R1,87,61,68
024-220598-120ZS 1 GS SMD 22K 1/8W J 0805 R118
024-220798-120ZS 1 GS SMD 2M2 1/8W J 0805 R80
024-237598-120ZS 1 GS SMD 23K7 1/8W F 0805 R48
024-270498-120ZS 2 GS SMD 2K7 1/8W J 0805 R73,64
024-280498-100ZS 2 GS SMD 2K8 1/8W F 0805 R51,53
024-300398-120ZS 1 GS SMD 300R 1/8W J 0805 R55
024-300598-120ZS 1 GS SMD 30K 1/8W J 0805 R56
024-330498-120ZS 8 GS SMD 3K3 1/8W J 0805 R7,8,12-15,59,67
024-330598-120ZS 2 GS SMD 33K 1/8W J 0805 R4,5
024-332498-100ZS 2 GS SMD 3K32 1/8W F 0805 R26,27
024-390498-120ZS 1 GS SMD 3K9 1/8W J 0805 R93
024-390598-120ZS 1 GS SMD 39K 1/8W J 0805 R77
024-430498-120ZS 1 GS SMD 4K3 1/8W J 0805 R78
024-453498-100ZS 1 GS SMD 4K53 1/8W F 0805 R36
024-453598-100ZS 1 GS SMD 45K3 1/8W F 0805 R30
024-470298-120ZS 2 GS SMD 47R 1/8W J 0805 R101,102
024-470398-120ZS 3 GS SMD 470R 1/8W J 0805 R76,99,100
024-470498-120ZS 2 GS SMD 4K7 1/8W J 0805 R85,86
024-470598-120ZS 4 GS SMD 47K 1/8W J 0805 R44,47,49,107
024-470698-120ZS 1 GS SMD 470K 1/8W J 0805 R70
024-470798-120ZS 1 GS SMD 4M7 1/8W J 0805 R60
024-510398-120ZS 1 GS SMD 510R 1/8W J 0805 R57
024-560498-120ZS 1 GS SMD 5K6 1/8W J 0805 R140,
024-560598-120ZS 1 GS SMD 56K 1/8W J 0805 R122
024-620398-100ZS 2 GS SMD 620R 1/8W F 0805 R16,18
024-680398-120ZS 1 GS SMD 680R 1/8W J 0805 R5A
