Infinity TSS-Sub1200 - Electrical Parts List

TSS-1200 120V ELECTRICAL PARTS LIST
Part Number Qty Description Reference Designator
Capacitors
032-270393-300ZR 1 GR Mylar cap. (ESK) 0u27/63V J (R) P:5 C29
034-100625-300ZS 1
GS electrolytic cap. 100uF/25V M (R)6.3x11 P:5
C64
034-220525-301ZS 5 GS Elect. Cap. 22uF/25V M (R)5x11 P:5 C4,9,41,50,53
034-330515-000ZS 1 GS elctrolytic cap. 33uF/16V M (R)0511 P:5 C39
034-330525-300ZR 1
GR electrolytic cap. 33uF/25V M (R)0511 P:5
C1
034-330615-300ZS 2
GS Electrolytic cap. 330uF/16V M (R)0812 P:5
C12,78
034-470415-301ZS 1 GS electrolytic cap. 4u7/50V M (R)0511 P:5 C2
034-470515-307ZR 1 GR electro cap. LOW ESR 85℃ESR<5Ω 47uF/16V M C65
035-100393-301ZR 1 GR Mylar cap. (ESK) 0u1/63V J P:5 ESK063S10JT C28,
035-220393-300ZR 1 GR PE cap. 0u22/63V J P:5 C27,
038-100363-300ZR 2 GR MPE cap. P:5 0u1/100V J C68,69
031-100144-103AZS 1 GS SMD 0u001/50V K 0805 X7R C79
031-100184-100AZS 2 GS SMD 0u01/250V K 0805 X7R C3,7
031-100244-100AZS 7
GS SMD Ceramic cap. 0u01/50V K 0805 X7R
C66,67,5,10C,33,45,51,
031-100343-100AZS 2 GS SMD 100pF/50V J 0805 NPO C36,58
031-100344-100AZS 18 GS SMD 0u1/50V K 0805 X7R
C11,42-44,46-49,52,54,55,60,63,
71,74,77,81,82,
031-220243-103AZS 1 GS SMD 0u022/50V J 0805 X7R C40
031-220344-300AZS 3 GS SMD 220pF/50V K 0805 NPO C20,21,19
031-330444-300ZS 1 GS SMD 3300pF/50V K 0805 X7R C34
031-470244-102AZS 2 GS SMD 0u047/50V K 0805 X7R C62,59
031-470344-100AZS 1 GS SMD 470pF/50V K 0805 X7R C80
031-560243-100AZS 2 GS SMD 56pF/50V J 0805 NPO C57,61
031-820343-101AZS 1 GS SMD 820pF/50V J 0805 NPO C56
032-820244-200ZR 1 GR mylar cap. 0u082/100V K (R) C30
033-470464-270ZS 1 GS NPE cap.1K 4u7/100V K10 (R)1015 GNE C73
033-680464-270ZS 1 GS NPE cap. 6u8/100V K10 (R)1020 GNE C72
034-100525-300ZS 1 GS Eletrolytic cap. 10uF/25V M (R)0511 P:5 C35
034-330780-300ZR 2
GR electrolytic cap. 85℃ 3300uF/80V M (R)22x48
C6,8
034-470515-200ZR 1
GR electro cap. 47uF/16V M (R)0511 P:2.5
C37
035-100393-301ZR 1
GR mylar cap. (ESK) 0u1/63V J P:5 PN:ESK063S10JT
C2A
035-100443-300ZR 2
GR mylar cap. (ESK) 1uF/63V J P:5 PN:ESK063W10JT
C25,26,
035-470293-300ZR 1 GR PE cap. 0u047/63V J P:5 C1A,
039-100384-100ZR 1 GR Safety cap.(0u1/250V) HQX0.1K275VACx2 CXAC1
032-100484-200ZS 2 GS END mylar cap. 1uF/250V K P:15 C70,C70B
Semiconductors
051-000600-100ZR 1 GR Transistor NPN MPSW06RLRA TO-92 (ON) Q16
051-222200-100ZR 1 GR Transistor NPN (ON) MPS2222ARLRAR TO-92 Q21
051-290700-100ZR 2 GR Transistor PNP (ON) MPS2907A RLRAR TO-92 Q19,23
054-000100-100ZR 5 GR GS SMD DIODE: ES1D 200V 1A (PANJIT) D5,26,29,33,38
054-007200-100ZR 3 SMD IC TL072CDR SO-8 DUAL OP-AMP U5,6,8,
054-007400-100ZR 2 SMD IC TL074CDR QUAD OP-AMP U2,3
054-008406-000ZR 1 GR SMD ZENER DIODE: BZX84C10-7-F SOT-23 D35
054-008407-000ZR 3 GR SMD ZENER DIODE: BZX84C15-7-F SOT-23 D6,7,9
054-008408-000ZR 2 GR SMD ZENER DIODE: BZX84C5V6-7-F SOT-23 D36,37
054-008409-000ZR 1 GR SMD ZENER DIODE: BZX84C3V0-7-F SOT-23 D25
054-011400-100ZR 1 GR SMD Transistor DTC114TKA SMT3 (ROHM Q7
054-033904-100ZR 8 GR SMD (TRANSISTOR) MMBT3904LT1G SOT23 Q11,14,13,5,8,25,9,27
054-033906-100ZR 4 GR SMD Transistor (ON) MMBT3906LT1G SOT23 Q6,10,12,15
054-045580-100ZS 1 GS SMD IC:(OP) NJM4558M-DUAL OP-AMP U4
054-414803-100ZS 23 GS SMD DIODE: LL4148 MINI-MELF
D1-4,8,27,30,31,34,39, 11,14,16,17,20-22,
18,19,28,32,44,45,
054-540100-100ZR 3
GR SMD Transistor PNP (ON SEN) MMBT5401 SOT-23
Q20,24,26
051-000600-100ZR 1 GR Transistor NPN MPSW06RLRA TO-92 (ON) Q2
TSS-Sub1200 subwoofer
13
