Table 3 Rear Panel Components
Component Description
Fan Modules Six field replaceable fan modules to help maintain optimum operating temperature. Each fan has an air vent that allows warm air to
flow out of the appliance. Do not obstruct.
UID LED Blue = UID is activated through pressing the UID button on the appliance or through the Grid Manager or CLI command
Dark = UID is deactivated
When UID is activated, the LCD on the front panel blinks at the same time.
UID Button The unit identification button. When you press the UID button, the LCD panel on the front panel blinks and the UID LED on the rear
panel glows blue. In a rack environment, the UID feature enables easier location of a server when moving between the front and rear
of the rack. You can also identify the appliance through the Grid Manager and CLI command.
Grounding
Post
For DC installations, you securely connect a grounding wire to the chassis and to earth ground, which typically is the equipment rack
on which you install the appliance. The mounting nut is placed on the grounding post for convenience. Remove the mounting nut, place
the grounding wire connector onto the grounding post and replace the mounting nut. Ensure that it is snug.
Power
Supplies
Each of the two redundant power supplies has a three-prong power outlet for connecting the appliance to a standard AC (Alternating
Current) power source.
