System, Environmental, and Power Specifications
System specifications describe the physical characteristics of the Infoblox 2205 Series appliances. Environmental specifications describe Infoblox 2205
Series temperature and moisture limits. Power specifications describe the electrical range within which the appliance circuitry can operate. Note that the
Infoblox 2205 appliance models use the CR2032 battery.
This chapter reports power usage and heat generation characteristics against the hardware configuration for the Infoblox 2205 Series appliances. Optional
hardware configurations that affect electrical power budgets include the following:
Use of a single power-supply or 1+1 redundant PSU (power supply unit) configuration (see ).Appliance Rear Panel
1 GbE SFP network interface card (see ). SFP/SFP+ Interface Support
10 GbE SFP+ network interface card (see ).SFP/SFP+ Interface Support
You may choose to order a field-replaceable power supply to upgrade your appliance to a 1+1 redundant configuration. Doing so changes the power
usage and heat generation characteristics for your appliance. The same is true if you change out your AC power supply configuration for DC power
supplies. Consult the specifications for your appliance for both AC and DC information.
System Specifications
Form : 2-U rack-mountable applianceFactor
Dimensions: 88mm H x 441mm W x 547mm D
Weight: Approximately 29 lbs (13.15 kg)
Ethernet : MGMT, HA, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-TPorts
Serial : DB-9 (9600/8n1, Xon/Xoff)Port
USB : USB 3.0Ports
Safety: FCC, CE, TUV, CB, VCCI, C-Tick, KCC, CCC, NOM, BIS, EAC
Environmental Specifications
Operating Temperature: 41°F – 95°F (5 – 35°C)
Storage Temperature: –40°F – 122°F (–40°C – 50°C)
Operating Relative Humidity: 5% to 95% (non-condensing)
Airflow CFM (Cubic Feet/Minute): 203 CFM
Airflow Direction: Front-to-Back
Environmental Certification: WEEE and RoHS
Electrical Power Specifications
AC Power Supply: 100 to 240VAC 600W (Maximum)
Input Frequency: 50 to 60 Hz
Input Current: 7.5A @ 100V AC, 3.5A @ 240V AC
Inrush Current: <25A max at 240V
Heat Output (BTU/hour): 2355 Max
Power Consumption
TE-22x5-BASE-AC: 283W
TE-22x5-1GE-AC: 291W
TE-22x5-10GE-AC: 308W
TE-22x5-BASE-DC: 251W
TE-22x5-1GE-DC:311W
TE-22x5-10GE-DC: 337W
PT-22x5-1GE-AC: 367W
PT-22x5-1GE-DC: 302W
PT-22x5-10G-AC: 447W
PT-22x5-10G-DC: 338W
ND-2205 and TR-2205-BASE-AC: 310W
ND-2205 and TR-2205-1GE-AC: 335W
ND-2205 and TR-2205-10GE-AC: 356W
ND-2205-BASE-DC: 308W
ND-2205-1GE-DC: 316W
ND-2205-10GE-DC: 335W
Fan FRU (Field-Replaceable Unit) SKU (Stock Keeping Unit)
The Infoblox 2205 Series appliances ship with inbuilt fans that can be replaced. The following table lists the fans supported on an Infoblox 2205 series
appliance:
