Introduction
12 Infoblox Installation Guide
System Specifications
• Form Factor: 1-U rack-mountable appliance
• Dimensions: 1.73” H x 17.36” W x 17.2” D (4.4 cm H x 44.1 cm W x 43.7 cm D)
• Weight: Approximately 24 to 28 pounds (10.9 to 12.7 kg)
• Ethernet Ports: MGMT, LAN1, LAN2 – auto-sensing 10Base-T/100Base-T/1000Base-T
• Serial Port: DB-9 (9600/8n1, Xon/Xoff)
• USB Port: USB2.0/1.1 compliant
• LCD Panel: LCD (liquid crystal display) with input buttons
Environmental Specifications
• Operating Temperature: 41 to 104 degrees F (5 to 40 degrees C)
• Storage Temperature: -13 to 158 degrees F (-25 to 70 degrees C)
• Operating relative Humidity: 10% to 90% (non-condensing)
Electrical Power Specifications
• AC Power Supply: Dual input, 450 Watts
— Input Voltage.: 90 – 264VAC
— Input Frequency: 47 – 63 HZ
— Input Current: 4A max at 230V
— Inrush Current: 20A max at 230V
— Power Factor: > 0.94/230V 50 Hz
