InFocus IN5122 Brochure & Specs

On-board Networking
Projector Management
Send commands over the network to the projector. Network administrators can
remotely access and control the projector over standard LAN/WAN. Conserve projector
lamp life by scheduling on/off times and presetting maintenance events. A network
bridge allows the IN5120 projectors to control attached serial devices.
Dynamic Messaging System
Send dynamic messages for instant display to the projectors – perfect for announcements
such as schedule changes, weather warnings, breaking news, and emergency
notifications.
Custom Start Up Screens
Create custom start up screens and send them over the network to specific projectors.
Reinforce your brand and get targeted messages to specific rooms throughout your facility.
Collaboration Tools at Your Command
Connect and Share Over the Network
Users can connect their PCs to IN5120
projectors over the network and share
visuals whether they’re in the room or
working remote.
Four screens can be displayed
simultaneously and switch from one user to
another with a click.
SplitScreen™
Present two sources side by side.
SplitScreen works with video and computer
sources. (Available on IN5124 only)
Present Without a PC.
Just Use a USB Thumb Drive.
Plug in a USB thumb drive and display JPG,
BMP, PNG, TIFF images. Leave your PC at
your desk.
Comprehensive Connectivity
HDMI 1.3 w/audio 5 BNC (RGBHV/YPbPr) D-Sub HD15 (VGA)
Component Video S-Video Composite Video
3.5 mm Stereo Jack(s) 3.5 mm Mono Jack for Microphone Wired Remote
USB Type A for PC-less Presentations USB Type B for USB Display
4 Assignable Audio Inputs
Easily configure the installation with the audio input options and connectors that
match your sources.
Customize Source Names
They’re your sources so you get to name them. Customize the name of sources to make
it easy for users to select the content they want.
Keep Your Projectors Where They Belong & Protect Your Investment
After your projector is installed it remembers and monitors its position with a transition
detector. If the projector moves, it prevents unauthorized use until it is reset with a
passcode.
Instant Stack for Virtual Dual Lamp Projection
Need 24/7 fail safe operation or nearly twice the
lumens? IN5120 projectors can be easily stacked,
aligned and controlled.
IN5120 Projectors can be
easily stacked
Project up to 4 computer screens
at the same time
1 2
3 4

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
