48
Appendix
Projected image size
NOTE: Visit the Service section of our website for interactive image size cal-
culators for the standard and optional lenses.
Standard Lens Features and Specifications:
• Motorized Zoom and Focus
• Lens Shift Position: 50-110% Vertical; +/-60% Horizontal
• F-Number: 2.0-2.32
• Focal Length: 21.5-28.7
• Screen Size: 30-500 inch
• Zoom Ratio: 1.33:1
• Throw Distance Ratio: 1.45-1.93:1 (WUXGA); 1.52-2.03:1 (WXGA)
Projection Size:
Standard Lens
WUXGA
Projection Distance (inch/
m) +/-10%
WXGA
Projection Distance (inch/
m) +/-10%
Screen Size
(inch/m) Minimum Maximum Minimum Maximum
30/0.8 37/0.9 49/1.2 39/1.0 52/1.3
40/1.0 49/1.2 65/1.7 52/1.3 69/1.7
60/1.5 74/1.9 98/2.5 77/2.0 103/2.6
70/1.8 86/2.2 115/2.9 90/2.3 121/3.1
100/2.5 123/3.1 164/4.2 129/3.3 172/4.4
120/3.0 148/3.7 196/5.0 155/3.9 207/5.2
150/3.8 184/4.7 245/6.2 193/4.9 258/6.6
200/5.1 246/6.2 327/8.3 258/6.5 344/8.7
250/6.3 307/7.8 409/10.4 322/8.2 430/10.9
300/7.6 369/9.4 491/12.5 387/9.8 516/13.1
400/10.2 492/12.5 655/16.6 516/13.1 689/17.5
500/12.7 615/15.6 818/20.8 644/16.4 861/21.9
Formula:
x=diag, y=dist
y=1.230x y=1.637x y=1.289x y=1.721x
