inform Pyramid DSP T User Manual

36
11 Technical Specifications
MODELS
Apparent power [kVA] 10 15 20 30 40 60 80 100 120
ENVIRONMENTAL
Storage temperature range
[°C] -25 to +55 (15 - 40 recommended for longer battery life)
Operating temperature
range [°C] 0 to +40 (20 - 25 recommended for longer battery life)
Relative humidity range % 0 - % 95 (non condensing)
Max. altitude without
derating [m] 1000
Protection level IP 20
Maximum
power
dissipation
[W] 800 960 1280 1920 2560 3840 5120 6400 7680
[Btu] 2730 3277 4369 6553 8737 13106 17475 21843 26212
[kcal/h] 688 825 1100 1650 2200 3302 4403 5503 6604
ELECTRICAL
Mains Input
Number of phases 3P+N+PE
Nominal voltage [V] 380 / 400 / 415 (line-line)
Voltage range
for normal
operation (line
to neutral) [V]
Lower
limit
(depends
on the
load
level)
187 @ %100 load ( line- neutral )
120 @ %64 load ( line- neutral )
80V@ %42 load ( line- neutral ) -
Upper
limit 280
Nominal frequency [Hz] 50 / 60
Frequency range [Hz] +/-10%
Nominal
current [A]
wave
form sinusoidal
rms value
*(2) 13 20 26 40 53 79 105 131 158
Maximum
current [A]
wave
form sinusoidal
rms value
17 23 30 47 61 95 125 158 195
OUTPUT
Performance classification
according to IEC 62040-3
VFI-SS-111
Number of phases 3P+N+PE
Nominal voltage [V] 380 / 400 / 415 (line-line)
Static voltage
regulation normal
<%1
@ %100 linear
load battery
Nominal frequency [Hz] 50 / 60
Free running frequency
[Hz] ± % 0.01
Voltage THD @ rated
linear load <%3
Nominal apparent power
[kVA] 10 15 20 30 40 60 80 100 120
Maximum load p. f. 0.8
Nominal active power [kW]
8 12 16 24 32 48 64 80 96
Nominal current [A] at
380V 15.2 22.7 30.3 45.5 60.6 91 121 151 181
Load crest factor @ rated
power 3:1
Overload duration >1min @ %150 load
Efficiency (normal
operation) @rated linear
load with 0.8 PF
>90
