Menu and submenu items
MAIN MENU SUBMENU MEANING
MEASURES MENU
LD%: 050 030 060 Output load
OPV: 220 221 219 V Output voltage
FREQU: 50.0 Hz Output frequency
IPV: 240 230 226 V Input voltages
BYP: 225 221 219 V Bypass source voltages
IPI: 031 040 020 A G input currents
BATT: 405 V 06.7A Battery voltage and charge current
TEMP: 24 C Cabinet inside heat
CHARGE LEVEL: 60% Battery charge level
ENTER EXIT Exit from submenu
ALARMS MENU
UPS STATUS Valid alarm
000>Date and alarm Recorded log events
ENTER CLEAR LOG Clearing log records
PARR.ERR.NR Parallel control board error nr.
ENTER EXIT Exit from submenu
INFORMATION MENU
SYNC :OK COMM :OK Syncronization and comminication
POWER: ……… VA Output power of the UPS
VERSION : MC1XX Version of UPS
FREQUENCY : PLL/XTAL Frequency generation mode
ENTER EXIT Exit from submenu
PASSWORD MENU
(password required ) System settings
ENTER EXIT Exit from submenu
SETTINGS MENU
MODE: Operation mode selection
UPS No : UPS number selection
REMOTE :ENABLE Remote access on/off
RESTART:ON/OFF Mains restored setting
BYP.PROTECT ON Bypass load protection
ENTER EXIT Exit from submenu
COMMAND MENU
SOUND : ON/OFF Sound alert on/off
ENTER B.TEST>432 Manuel battery test
ENTER <BYPASS> Manuel bypass
ENTER:MODEM INIT Modem settings
ENTER <BOOST> Boost charge on/off
SIMULATION OFF Simulation mode selection
ENTER EXIT Exit from submenu
TIME MENU
TIME : 23 :15 time
DATE : 11-10-2001 date
SET HOURS: 11 Adjust hours
SET MINS : 38 Adjust minutes
SET DAY : 21 Adjust day
SET MONTH : 06 Adjust month
SET YEAR : 2001 Adjust year
ENTER <UPDATE> Write new time and date
ENTER EXIT Exit from submenu
