4.4 MAIN Menu
The main menu items are given at the following table you can move on main menu items by using DOWN
key.
Main Menu item Function
STATUS MENU
The status message which shows the UPS status
MEASURES MENU
→ Enter "go to Meausures submenu"
ALARMS
→ Enter "go to Alarms submenu"
INFORMATION MENU
→ Enter "go to İnformation submenu"
PASSWORD MENU
→ Enter "go to password submenu"
SETTINGS MENU
→ Enter "go to Settings submenu"
COMMAND MENU
→ Enter "go to Command submenu"
TIME MENU
→ Enter "go to Time and date submenu"
Go to STATUS MENU
4.5 MEASURES MENU Items
At this menu you can see all measured values, use DOWN key for moving on submenu items.
Submenu item Function
1 LD%: 060 074 080
Output load percentage (capacity %)
2 OPV: 220 221 220
Output voltages
3 FREQU: 50.0 Hz
Output frequency
4 IPV: 240 235 220
Input voltages
5 BYP: 230 232 231
Bypass source voltages
6 IPI: 022 010 030
Input currents (amperes)
7 BATT: 405 V 22.1 A
Battery voltage and charge current
8 TEMP: 030 c
Cabinet inside temperature
9 CHARGE LEVEL :%100
Battery charge level
10 ENTER EXIT
→ Enter (↵ ) exit from menu
Goto first submenu item
4.6 ALARMS Menu Items
At this menu you can see recorded log events and valid alarms
Submenu item Function
1 UPS STATUS
Valid alarm is on LCD PANEL
2 000>311201 23:15
See recorded log events :
At the first line the first 3 numbers shows the event number. 000 numbered
event is the last event. Date ddmmyy time:hh:mm
At the second line of LCD PANEL you can see all recorded alarms.
Use PLUS and MINUS keys for moving on events.
3 ENTER CLEAR LOG
→ Enter (↵ ) clear log event records
After you cleared events you see EMPTY LOG message at lines
4 PARR.ERR.NR : 017
Parallel control board fault number. (use if the parallel board is installed)
0 means that there is no error on parallel board
5 ENTER EXIT
→ Enter (↵ ) exit from submenu
Goto first submenu item
