6 . D E S C R I P T I O N
X 1 EX – 5 0 0 / 7 0 0 / 1 0 0 0 F R O N T P A N E L
X 1 EX – 1 2 5 0 F R O N T P A N E L
X 1 EX– 160 0 / 2 0 0 0 F R O N T P A N E L
On/Off Switch
Green lighting: AC mode
Green flashing: Battery mode
On/Off Switch
Red led on: Fault
Yellow flashing: Battery mode
Green lighting: AC mode
On/Off Switch
Red led on: Fault
Gradually lighting green LEDs in:
- AC mode: load level
- Battery mode: battery capacity
Green lighting: AC mode
Green flashing: Battery mode
