INFOSEC UPS SYSTEM X1 EX Series - Rear Panel Overview

INFOSEC UPS SYSTEM - 4, rue de la Rigotière - 44700 Orvault - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 03 15 AA 59 204 31
6
B A C K P A N E L
X 1 EX – 5 0 0 / 7 0 0 / 1 0 0 0 R E A R P A N E L
X 1 EX – 1 2 5 0 R E A R P A N E L
X 1 EX – 160 0 / 2 0 0 0 R E A R P A N E L
Optional USB
2 protected UPS outlets
AC Input Cable
Optional USB port
Breaker
AC Input Cable
Optional USB port
Fuse
AC Input Outlet
4 protected UPS outlets
4 protected UPS outlets
Breaker
